SILICON POWER - DDR3L - module - 8 GB - SO-DIMM 204-pin - 1600 MHz / PC3L-12800 - CL11 - 1.35 V - unbuffered - non-ECC | SP008GLSTU160N02
Please sign in so that we can notify you about a reply
Special Fetures
- Fast data transfer rates
- Dual rank
- Reset pin for improved system stability
- Nominal and dynamic on-die termination (ODT) for data, strobe, and mask signals
- Adjustable data-output drive strength
- Fly-by topology
- Terminated control, command, and address bus
- Serial presence-detect (SPD)
- Pb-free
Product Specification
| Capacity | 8 GB |
| Upgrade Type | Generic |
| Memory | |
| Type | DRAM memory module |
| Technology | DDR3L SDRAM |
| Form Factor | SO-DIMM 204-pin |
| Module Height (inch) | 1.19 |
| Speed | 1600 MHz (PC3L-12800) |
| Latency Timings | CL11 (11-11-11) |
| Data Integrity Check | Non-ECC |
| Features | Dual rank, On-Die Termination (ODT), Serial Presence Detect (SPD), Low Voltage, unbuffered |
| Module Configuration | 1024 x 64 |
| Chips Organization | 512 x 8 |
| Voltage | 1.35 V |
| Lead Plating | Gold |
| Manufacturer Warranty | |
| Service & Support | Limited lifetime warranty |
Features - Silicon Power - SP008GLSTU160N02
More Details
Product Code
04:164821
EAN Code
4712702631258
Manufacturer
Silicon Power
