StarTech.com 2-Port Hybrid USB-C HDMI Cable KVM Switch / 4K 60Hz | C2-H46-UAC-CBL-KVM
Product Features
- Hassle-free setup
The KVM switch is bus powered and features built-in HDMI, USB-A, USB-C, and 3.5 mm Audio Input/Output cables. This ensures compatibility and performance between the KVM switch, monitors, and peripherals - without the need to select and purchase the cables required for those connections. - Compatibility powerful
The 2-port KVM switch is compatible with all operating systems, including Windows, macOS, ChromeOS, and Linux. The KVM works with all hardware platforms including Intel, AMD, and Apple M1/M2. The USB-C host port works with USB-C, USB4, Thunderbolt 3, and Thunderbolt 4 laptops. If the desktop does not have a 4-position 3.5 mm port the included 3.5 mm Headset Adapter ensures compatibility out of the box. - Intuitive control
The KVM switch offers two options to switch between hosts - a remote push button or hotkey commands. The remote push button includes a 1.5 m cable for optimal placement in the setup. Independent audio switching can be achieved through the software, ensuring uninterrupted audio when switching between host devices.
Special Features
- 4K 60 Hz hybrid KVM switch - enables switching between a USB-A/HDMI desktop and a USB Type-C DP-Alt Mode enabled laptop to share a keyboard, mouse, audio input/output devices, and a single 4K 60 Hz HDMI monitor
- Ready-to-use - small form factor, integrated cables, and no external power adapter enable rapid deployment, bus-powered KVM switch features built-in 6 ft/1.8 m USB-A, HDMI, and Audio host cables for PC1, and 4 ft/1.2 m USB-C and Audio host cables for PC2
Product Specification
Device Type | KVM / audio / USB switch - 2 ports |
Enclosure Type | Desktop |
Subtype | KVM |
Ports | 2 x KVM / audio / USB |
KVM Local Users Qty | 1 local user |
Keyboard / Mouse Interface | USB |
Max Resolution | 4096 x 2160 @ 60 Hz |
Features | USB powered, remote switch, DisplayPort Alternate mode, 2.1 channel audio support, ABS housing, Auto Scan mode |
Compliant Standards | USB 2.0 |
Status Indicators | Port status |
Expansion / Connectivity | Expansion / Connectivity |
Interfaces | 1 x USB input Type C ¦ 2 x audio input mini-jack ¦ 1 x USB 2.0 Type A ¦ 1 x HDMI input ¦ 2 x USB 2.0 output Type A ¦ 1 x audio output mini-jack ¦ 1 x microphone output mini-jack ¦ 1 x HDMI output |
Miscellaneous | Miscellaneous |
Colour | Black |
Included Accessories | 4-position to 2 x 3-position 3.5 mm headset adapter |
Cables Included | 1 x USB-C cable - 1.2 m ¦ 1 x audio cable - 1.2 m ¦ 1 x audio / USB cable - 1.8 m ¦ 1 x HDMI cable - 1.8 m ¦ 1 x remote control cable - 1.5 m |
MTBF | 345,059 hours |
Compliant Standards | RoHS, WEEE |
Software / System Requirements | Software / System Requirements |
OS Required | Linux, Google Chrome OS, Apple macOS 10.12 - 10.15, Apple macOS 11.0, Microsoft Windows 7 / 8 / 8.1 / 10 / 11, Apple macOS 12.0 |
Dimensions & Weight | Dimensions & Weight |
Width | 9.2 cm |
Depth | 9.7 cm |
Height | 2.4 cm |
Weight | 265 g |
Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
Shipping Width | 21 cm |
Shipping Depth | 16 cm |
Shipping Height | 6 cm |
Shipping Weight | 500 g |
Manufacturer Warranty | Manufacturer Warranty |
Service & Support | Limited warranty - 2 years |
Environmental Parameters | Environmental Parameters |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 40 °C |
Humidity Range Operating | 0 - 90% RH (non-condensing) |
Min Storage Temperature | -20 °C |
Max Storage Temperature | 60 °C |
