StarTech.com Multimode (MM) SC Fiber Media Converter for 1Gbe Network / 550m Range / GigE / 1000Base-LX, 1000Base-SX, 1000Base-T / RJ-45 / SC multi-mode / up to 550 m / 850 nm | ET91000SC2
StarTech.com Multimode (MM) SC Fiber Media Converter for 1Gbe Network / 550m Range / Gigabit Ethernet -Remote Monitoring / 850nm (ET91000SC2) / Fibre media converter / GigE / 1000Base-LX, 1000Base-SX, 1000Base-T / RJ-45 / SC multi-mode / up to 550 m / 850 nm / for P/N: ETCHS2U, SVA12M2NEUA, SVA12M5NA | ET91000SC2
Description
Convert and extend a Gigabit Ethernet connection up to 550 m / 1804 ft over Multi Mode SC fiber. The ET91000SC2 1000 Mbps Gigabit Multimode Fiber Media Converter (SC, 550m) lets you extend a Gigabit Ethernet network over multimode fiber, at distances up to 550m (1804 ft).A cost-effective solution for connecting a Gigabit Ethernet (1000Base-T) network to remote network segments over a (1000Base-LX/SX) fiber backbone, the GbE to MM fiber converter supports full Gigabit speeds for ideal network performance and scalability. Designed to offer a durable and convenient Ethernet to fiber solution, this Ethernet to SC Fiber converter features an all-steel chassis, and a simple plug-and-play installation with minimal configuration required.For added versatility, the fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U).
Product Specification
| Device Type | Fibre media converter |
| Form Factor | External |
| Colour | Black |
| Localisation | North America, United Kingdom, Europe |
| Connectivity Technology | Wired |
| Cabling Type | 1000Base-LX, 1000Base-SX, 1000Base-T |
| Data Link Protocol | GigE |
| Data Transfer Rate | 1 Gbps |
| Optical Wave Length | 850 nm |
| Max Transfer Distance | 550 m |
| Features | Auto-uplink (auto MDI/MDI-X), half duplex mode, full duplex mode, rugged |
| Interfaces | 1 x Ethernet 1000Base-T - RJ-45 female ¦ 1 x Ethernet 1000Base-LX/1000Base-SX - SC multi-mode female x 2 |
| MTBF | 65,000 hours |
| Compliant Standards | Plug and Play, FCC, RoHS |
| Power Device | External power adapter |
| Voltage Required | AC 120/230 V |
| Width | 9.5 cm |
| Depth | 16 cm |
| Height | 2 cm |
| Weight | 0.62 kg |
| Service & Support | Limited warranty - 2 years |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 60 °C |
| Humidity Range Operating | 10 - 90% |
| Designed For | P/N: ETCHS2U, SVA12M2NEUA, SVA12M5NA |
