StarTech.com PCIe Gigabit Ethernet Fiber Network Card / PCIe GbE SFP Network Card Adapter / low profile / GigE | PEX1000SFP2
Please sign in so that we can notify you about a reply
Special Features
- Supports full/half-duplex auto-negotiation, auto-MDI/MDIX
- Jumbo frame support
- Supports PCI Message Signaled Interrupt (MSI)
- Preboot Execution Environment (PXE) 2.1
Product Specification
| Device Type | Network adapter |
| Form Factor | Plug-in card - low profile |
| Interface (Bus) Type | PCI Express x1 |
| Networking | Networking |
| Connectivity Technology | Wired |
| Cabling Type | Ethernet 1000Base-LX, Ethernet 1000Base-SX |
| Data Link Protocol | Gigabit Ethernet |
| Data Transfer Rate | 1 Gbps |
| Remote Management Protocol | SNMP 1 |
| Status Indicators | Link OK, link/activity |
| Features | Flow control, full duplex capability, auto-uplink (auto MDI/MDI-X), Jumbo Frames support, 48KB packet buffer, PXE 2.1 support |
| Compliant Standards | IEEE 802.3z, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 - SFP (mini-GBIC) |
| Miscellaneous | Miscellaneous |
| Included Accessories | Low-profile bracket |
| Compliant Standards | FCC, RoHS |
| Power | Power |
| Power Consumption Operational | 3.2 Watt |
| Software / System Requirements | Software / System Requirements |
| Software Included | Drivers & Utilities |
| OS Required | Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Apple MacOS X 10.5 - 10.9, Microsoft Windows XP / Vista / 7 / 8 / 8.1 / 10, Microsoft Windows Server 2016, Linux 2.4.x to 4.11.x LTS versions only |
| Dimensions & Weight | Dimensions & Weight |
| Width | 1.8 cm |
| Depth | 12.8 cm |
| Height | 11.8 cm |
| Weight | 57 g |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 2 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Compatibility Information | Compatibility Information |
| Designed For | P/N: 3CSFP91ST, 453154B21ST, ET91000SM10, ET91000SM20, EXSFP1GELXST, EXSFP1GESXST, EXSFP1GETST, GLCEXSMDST, GLCLHSM10PST, GLCLHSMD10ST, GLCLHSMDST, GLCLHSMDSTTA, GLCLXSMRGDST, GLCSXMM10PST, GLCSXMMDST, GLCSXMMDSTT, GLCSXMMRGDST, GLCT10PKST, GLCTEST, GLCTST, GLCTSTTAA, GLCZXSMRGDST, J4858C10PKST, J4858CST, J4859C10PKST, J4859CST, J8177C10PKST, J8177CST, JD089BST, JD118BST, JD119BST, MASFP1GBLX10, MASFP1GBSXST, MASFP1GBTXST, SFP1GELXST, SFPC1110, SFPG1320C, SFPGESST, SFPGLCLHSMST, SFPGLCSXMMST, SFPSXMM |
Features - StarTech.com - PEX1000SFP2
More Details
Product Code
03:194252
EAN Code
0065030857383
Manufacturer
StarTech.com
