StarTech.com Quad Port 10G SFP+ Network Card / Intel XL710 Open SFP+ Converged Adapter / PCIe 10 Gigabit Fiber Optic Server NIC / 10GbE | PEX10GSFP4I

PEX10GSFP4I
756.07
(899.72 inc. VAT)
Out of stock
Find similar
Delivery
Payment options
Product CodeV934061 EAN Code0065030867740 ManufacturerStarTech.com

StarTech.com Quad Port 10G SFP+ Network Card / Intel XL710 Open SFP+ Converged Adapter / PCIe 10 Gigabit Fiber Optic Server NIC / 10GbE / Network adapter / PCIe x8 / 10 Gigabit SFP+ x 4 / black | PEX10GSFP4I

Description

This SFP+ server network card delivers reliable, high-performance network connectivity, by adding four open SFP+ slots to your server or high-powered workstation. It provides an easy and cost-effective way to upgrade to a 10 Gigabit fiber network using SFP+ modules of your choice and gives you the flexibility to use either multimode or single-mode fiber.

StarTech.com Quad Port 10G SFP+ Network Card / Intel XL710 Open SFP+ Converged Adapter | PEX10GSFP4I

Special Features

  • Add redundant connections in zero-downtime environments
  • Increase your network speed
  • Add scalable network connections to your server or workstation
  • Enhance your network capabilities

Product features

  • Add redundant connections in zero-downtime environments
    With multiple available ports, you can avoid network downtime by adding fault-tolerant connections using two or more modules to provide high-bandwidth network links to your mission-critical servers or workstations.
  • Increase your network speed
    This PCIe network card lets you take advantage of the increased speed and stability of a 10 Gigabit network, with data transfers of up to 10Gbps.
  • Add scalable network connections to your server or workstation
    The network interface card is compatible with most 10GbE SFP+ transceivers. This gives you flexible and scalable configuration options, for connecting your computer directly to a fiber network at greater distances.
  • Enhance your network capabilities
    The SFP+ server network card features the Intel XL710 chipset, delivering the power, performance and enhanced capabilities you need for reliable connections to your server or computer. The Intel chip offers many advanced features including Intel Virtualization Technology for Connectivity, PXE network boot support and up to 9K jumbo frame support.


Product Specification

Device Type Network adapter
Form Factor Plug-in card
Interface (Bus) Type PCI Express x8
Ports 10 Gigabit SFP+ x 4
Connectivity Technology Wired
Cabling Type Ethernet 10GBase-LR, Ethernet 10GBase-SR
Data Link Protocol 10 Gigabit Ethernet
Data Transfer Rate 20 Gbps
Capacity Jumbo frame size: 9000
Features Full duplex capability, Jumbo Frames support
Compliant Standards IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae
Processor Intel XL710
Interfaces 4 x 10GBase-LR - SFP+
Compliant Standards FCC, RoHS, WEEE, RCM
Colour Black
OS Required Microsoft Windows Server 2008 R2 (64-bits), Microsoft Windows Server 2012 (64-bit), Microsoft Windows Server 2012 R2 (64-bit), Microsoft Windows 7 / 8 / 8.1 / 10 (64 bits), Microsoft Windows Server 2016 (64-bit), Linux 2.6.24 - 4.11.x (64-bit) LTS versions, Microsoft Windows Server 2019 (64-bit)
Width 15 cm
Depth 13.9 cm
Height 12 cm
Weight 129 g
Service & Support Limited warranty - 2 years
Min Operating Temperature 5 °C
Max Operating Temperature 50 °C
Humidity Range Operating 20 - 80%

Features - StarTech.com - PEX10GSFP4I

More Details
Product Code
V934061
EAN Code
0065030867740
Manufacturer
StarTech.com
