StarTech.com 4-Bay SATA SSD/HDD Docking Station / External USB 3.1 (10Gbps) SATA SS/HDD Dock for 2.5"/3.5" SSDs/HDDs (SDOCK4U313) / Storage enclosure / 2.5" / 3.5" shared / SATA 6Gb/s / 600 MBps / USB 3.1 (Gen 2) / black | SDOCK4U313
StarTech.com 4-Bay SATA SSD/HDD Docking Station / External USB 3.1 (10Gbps) SATA SS/HDD Dock for 2.5"/3.5" SSDs/HDDs (SDOCK4U313) / Storage enclosure / 2.5" / 3.5" shared / SATA 6Gb/s / 600 MBps / USB 3.1 (Gen 2) / black | SDOCK4U313
Description
Gain quick access to up to four SSDs/HDDs simultaneously, while also being able to swap drives in and out as needed. This 4-bay SATA HDD docking station lets you access up to four solid-state drives or hard drives simultaneously over USB 3.1 (10Gbps), and hot swap drives with ease. Ideal for IT professionals, the docking station provides large data capacity and fast file transfers, helping you manage your workflow more efficiently.When you're managing a large number of drives, the HDD/SSD docking station saves you time. Quickly dock and swap your drives for disk imaging, data recovery from failing drives, data backups, or other tasks.The hard drive docking station also has SMART support, for accessing important drive information such as hours in use, number of power cycles, and disk health.With USB 3.1 Gen 2, the HDD docking station lets you leverage the high performance of the latest SSDs and hard drives, while alleviating bottlenecks in your data transfers.The hard drive docking station includes a USB Type-C cable, for connecting to USB-C equipped laptops and devices, and a USB Type-A cable, for backward compatibility with your existing USB 3.0, 2.0 and 1.x devices.The docking station also works with 2.5" and 3.5" IDE hard drives, mSATA drives and M.2 drives using a compatible StarTech.com adapter:IDE hard drives: Use StarTech.com adapter SAT2IDEADP SATA to 2.5in or 3.5in IDE Hard Drive Adapter for HDD Docks.mSATA drives: Use StarTech.com adapter SAT32MSAT257 mSATA SSD to 2.5in SATA Adapter Converter.M.2 drives: Use StarTech.com adapter SAT32M225 M.2 NGFF SSD to 2.5in SATA Adapter Converter.
StarTech.com 4-Bay SATA SSD / HDD Docking Station | SDOCK4U313
Special Features
- Quad-bay top-loading design with independent drive doors, drive controllers, power switching, and ejection buttons
- Access up to four 2.5â€/3.5†SSDs/HDDs simultaneously over USB 3.1 (10Gbps), and hot swap drives
- USB Type-C and USB Type-A interface, backward compatible with USB 3.0, 2.0 and 1.x
Product Specification
| Device Type | Storage enclosure - external |
| Hard Drive Form Factor Compatibility | 2.5" / 3.5" shared |
| Host Bus | USB 3.1 (Gen 2) |
| Product Material | Plastic |
| Colour | Black |
| Localisation | Australia, Japan, New Zealand, United Kingdom, Europe, North Asia |
| Interface | SATA 6Gb/s |
| Data Transfer Rate | 600 MBps |
| Supported Devices | Hard drive, solid state drive |
| Max Storage Devices Qty | 4 |
| Processor | VIA Labs VL820 / VL715 |
| Bays | 4 x hot-swap - 2.5" / 3.5" shared |
| Interfaces | 1 x SATA 6Gb/s - SATA combo |
| Connections | 1 x USB 3.1 (Gen 2) - 24 pin USB-C |
| Cables Included | 1 x USB-C 3.1 cable - external - 1 m ¦ 1 x USB 3.1 cable - external - 1 m |
| Features | Built-in 2 cooling fans, S.M.A.R.T. support, 4 LED indicators, tested with up to 10TB, TRIM support, 4Kn drive compatible |
| MTBF | 30,000 hours |
| Compliant Standards | FCC, RoHS, UASP (USB Attached SCSI Protocol) |
| Power Source | USB bus |
| Type | Power adapter |
| Voltage Required | AC 120/230 V |
| Power Consumption Operational | 78 Watt |
| Service & Support | Limited warranty - 2 years |
| Width | 17.1 cm |
| Depth | 29.1 cm |
| Height | 8.7 cm |
| Weight | 1 kg |
| Shipping Weight | 2.4 kg |
| Min Operating Temperature | 5 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 20 - 80% |
