StarTech.com 4 Port PCI Express RS232 Serial Adapter Card / 16950 UART / 256-byte FIFO Cache / PCI E Serial Card / Serial adapter / PCIe / RS-232 x 4 | PEX4S953
Please sign in so that we can notify you about a reply
StarTech.com 4 Port PCI Express RS232 Serial Adapter Card / 16950 UART / 256-byte FIFO Cache / PCI E Serial Card / Serial adapter / PCIe / RS-232 x 4 | PEX4S953
Description
This adapter card lets you add four RS-232 serial ports to your computer through a PCIe slot, as if they were native serial ports. The dual port PCIe serial card enables you to interact with serial devices, such as card readers, printers, PIN pads, and modems. The card comes pre-configured with a full-profile bracket, and includes low-profile brackets, so installation is easy regardless of the case form factor.
StarTech.com 4 Port PCI Express RS232 Serial Adapter Card / 16950 UART | PEX4S953
Special Features
- Maximum compatibility
- Easy installation
Product Specification
| Device Type | Serial adapter |
| Form Factor | Plug-in card |
| Interface (Bus) Type | PCI Express x1 |
| PCI Specification Revision | PCIe 1.1 |
| Ports | RS-232 x 4 |
| Connectivity Technology | Wired |
| Data Link Protocol | RS-232 |
| Data Transfer Rate | 921.6 Kbps |
| Features | Full duplex mode, 256-byte FIFO |
| Processor | AX99100 - ASIX |
| Interfaces | 4 x RS-232 - 9 pin D-Sub (DB-9) (on cable) ¦ 1 x SATA power - 15 pin Serial ATA power (internal) |
| Compliant Standards | FCC, RoHS, WEEE, REACH |
| OS Required | Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows 7 / 8 / 8.1 / 10, Microsoft Windows Server 2016, Linux 2.4.x - 2.6.x LTS versions only |
| Depth | 6.3 cm |
| Shipping Width | 21.3 cm |
| Shipping Depth | 14.9 cm |
| Shipping Height | 5.1 cm |
| Shipping Weight | 386 g |
| Service & Support | Limited warranty - lifetime |
| Min Operating Temperature | -10 °C |
| Max Operating Temperature | 80 °C |
| Humidity Range Operating | 5 - 85% |
Features - StarTech.com - PEX4S953
More Details
Product Code
V934950
EAN Code
0065030888257
Manufacturer
StarTech.com
