StarTech.com Dual Monitor USB C Dock / Windows/Mac / 4K DP/HDMI, 60W PD, SD / Docking station / USB-C / GigE / 60 Watt | DK30CHDPPDUE
StarTech.com Dual Monitor USB C Dock / Windows/Mac / 4K DP/HDMI, 60W PD, SD / Docking station / USB-C / GigE / 60 Watt | DK30CHDPPDUE
Description Add dual monitors (4K HDMI & 4K DP), an SD card reader, multiple USB ports, GbE, and audio to your laptop, plus power and charge your laptop. This dual-monitor USB-C dock transforms your MacBook or Windows laptop into a dual Ultra HD 4K workstation, with support for 4K DisplayPort and HDMI monitors. It gives you all the connections to create a fully capable workstation, including an SD card reader slot.The USB-C docking station features USB Power Delivery 2.0 (60W), to power and charge your laptop as you work. It's the perfect companion for your MacBook Pro or other Thunderbolt 3 equipped laptop.The USB-C dock expands the display capabilities of your laptop across two Ultra HD 4K monitors. It enables DisplayLink and USB-C DP Alt Mode to allow dual 4K video output to HDMI and DisplayPort 4K monitors. With the dual-4K dock, you can connect: 1x 4K DisplayPort display at 3840 x 2160 resolution @ 30Hz; 1x 4K HDMI display at 3840 x 2160 resolution @ 30Hz.The dock provides direct access to your SD memory cards or microSD cards (with adapter). The SD card slot can also be used for additional storage and backup through macOS X Time Machine or Windows 10 File History.The dock provides four USB 3.0 (Type-A) ports to connect your peripherals, including a USB 3.0 fast-charge and sync port, a Gigabit Ethernet port, and combined 3.5 mm audio and microphone port.Compatible with Mac and Windows, this universal dock works with USB-C and Thunderbolt 3 enabled laptops. |
Product Specification
Product Type | Docking station |
Width | 8 cm |
Depth | 22 cm |
Height | 2.5 cm |
Weight | 385 g |
Enclosure Colour | Black, silver |
Localisation | United Kingdom, Europe |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, USB 1.1, USB 2.0, USB 3.0, USB 3.1 |
Expansion Slots | 1 (total) / 1 (free) x SD / MMC Memory Card |
Interfaces | 1 x USB-C - input - 24 pin USB-C ¦ 4 x SuperSpeed USB 3.0 - output - 9 pin USB Type A ¦ 1 x display / video - HDMI output - 19 pin HDMI Type A ¦ 1 x display / video - DisplayPort output - 20 pin DisplayPort ¦ 1 x audio - output - mini-phone 3.5 mm 4-pole ¦ 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 |
Compatible Slots | 1 x SD / MMC Memory Card |
Cables Included | 1 x USB-C cable - external |
Features | Dual monitor support, UASP transfer protocol, 1 USB 3.0 fast charging port, DisplayLink DL-5700 chipset, Genesys Logic GL3515 chipset, VLI VL813 chipset, Texas Instruments TPS65983 chipset |
Power Device | Power adapter |
Voltage Required | AC 120/230 V |
Power Provided | 60 Watt |
OS Required | Google Chrome OS, Microsoft Windows 7 / 8 / 8.1 / 10, Apple MacOS X 10.11 - 10.13.3 |
Service & Support | Limited warranty - 3 years |
Shipping Weight | 1.4 kg |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 60 °C |
