StarTech.com 3 Bay Aluminum Trayless Hot Swap Mobile Rack Backplane for 3.5in SAS II/SATA III - 6 Gbps HDD
HSB3SATSASBA
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
StarTech.com HSB3SATSASBA StarTech.com 3 Bay Aluminum Trayless Hot Swap Mobile Rack Backplane for 3.5in SAS II/SATA III - 6 Gbps HDD
Easily connect and hot swap up to three 3.5 SATA/SAS hard drives from two 5.25 baysThe HSB3SATSASBA Removable 3-drive backplane lets you quickly install and hot-swap 3.5" drives from the front of your computer, by turning two 5.25" bays into a hot-swappable interface for you to connect up to three 3.5 SATA or SAS hard drives HDD.
For added versatility, the hard drive bay can interface with SATA I/II/III and SAS I/II hard drives -- an ideal accommodation for enterprise system applications.
For a quick and secure method of installing and removing drives, the backplane features ejection levers and a key-lock design. To help prevent drive failure, the bay provides excellent heat dissipation with a built-in fan, and a vented solid aluminum enclosure.
The HSB3SATSASBA is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Delivers peak drive performance, with support for full SATA III/SAS II data transfer speeds up to 6Gbps
- Flexible drive options with support for both SATA and SAS drive interfaces
- Helps maintain ideal drive operating temperatures by providing excellent heat dissipation, vented aluminum housing and a built-in fan
Feature list
| Storage drives installed: | N |
| Supported storage drive types: | HDD |
| Number of storage drives supported: | 3 |
| Maximum supported storage capacity: | 12 TB |
| Storage drive interface: | Serial ATA, Serial ATA II, Serial ATA III, Serial Attached SCSI |
| Storage drive size: | 3.5 " |
| Data transfer rate: | 6 Gbit/s |
| Hot-swap drive bays: | Y |
| Internal: | N |
| Colour of product: | Black |
| LED indicators: | Activity, Power |
| Number of fans: | 1 |
| RoHS compliance: | Y |
| Width: | 145 mm |
| Depth: | 194.1 mm |
| Package width: | 125 mm |
| Package depth: | 254 mm |
| Package height: | 180 mm |
| Package weight: | 1200 g |
| Cables included: | SATA |
| Operating temperature T-T: | 0 - 55 °C |
| Operating relative humidity H-H: | 5 - 85 % |
| Storage temperature T-T: | -20 - 60 °C |
