StarTech.com Cisco Meraki MA-SFP-1GB-TX Compatible SFP Module / 10BASE-T / 10/100/1000 Mbps SFP to RJ45 Cat6/Cat5e Transceiver / 100m / SFP (mini-GBIC) transceiver module (equivalent to: Cisco Meraki MA-SFP-1GB-TX) / GigE / 1000Base-T / RJ-45 / up to 100 m | MASFP1GBTXST
Description
The MASFP1GBSXST is a Cisco Meraki MA-SFP-1GB-SX compatible copper transceiver module that has been designed, programmed and tested to work with Cisco Meraki brand switches and routers. It delivers dependable 1GbE (1000 Mbps) connectivity over copper cable, for 10BASE-T, 1000BASE-T and 100BASE-TX compliant networks, with a maximum distance of up to 100 m (328 ft).This SFP copper module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.
Product Specification
| Device Type | SFP (mini-GBIC) transceiver module |
| Form Factor | Plug-in module |
| Colour | Silver |
| Connectivity Technology | Wired |
| Cabling Type | 1000Base-T |
| Data Link Protocol | GigE |
| Data Transfer Rate | 1 Gbps |
| Max Transfer Distance | 100 m |
| Features | Auto-negotiation, full duplex mode |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| Interfaces | 1 x Ethernet 1000Base-T - RJ-45 female |
| Compliant Standards | UL, FCC, RoHS, MSA |
| OEM Manufacturer Equivalent Part Number | Cisco Meraki MA-SFP-1GB-TX |
| Width | 1.37 cm |
| Depth | 6.8 cm |
| Height | 1.38 cm |
| Weight | 35 g |
| Service & Support | Limited warranty - lifetime |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 70 °C |
| Humidity Range Operating | 5 - 95% |
Features - StarTech.com - MASFP1GBTXST
More Details
Product Code
V933912
EAN Code
0065030869461
Manufacturer
StarTech.com
