StarTech.com Extreme Networks 10057H SFP Module - Upstream / SFP (mini-GBIC) transceiver module (equivalent to: Extreme Networks 10057H) / GigE / 1000Base-BX-U / LC single-mode / up to 10 km / 1310 (RX) / 1490 (TX) nm | 10057H-ST
Description
The 10057H-ST is an Extreme Networks 10057H compatible upstream fiber SFP transceiver which pairs with StarTech.com's 10056H-ST. They are designed, programmed and tested to work with 1000Base-BX-U compatible Extreme Networks switches and routers. The SFP transceiver module supports a maximum distance of up to 10 km (6.2 mi) and delivers dependable 1 GbE connectivity over fiber cabling.This SFP fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.
Product Specification
| Device Type | SFP (mini-GBIC) transceiver module |
| Form Factor | Plug-in module |
| Connectivity Technology | Wired |
| Cabling Type | 1000Base-BX-U |
| Data Link Protocol | GigE |
| Data Transfer Rate | 1 Gbps |
| Optical Wave Length | 1310 (RX) / 1490 (TX) nm |
| Max Transfer Distance | 10 km |
| Features | Full duplex mode, Digital Diagnostics Monitoring (DDM) |
| Interfaces | 1 x Ethernet 1000Base-BX-U - LC single-mode female |
| MTBF | 286,217,327 hours |
| Compliant Standards | FCC, RoHS, REACH, MSA |
| OEM Manufacturer Equivalent Part Number | Extreme Networks 10057H |
| Power Consumption Operational | 1.3 Watt |
| Width | 5.66 cm |
| Depth | 1.37 cm |
| Height | 1.25 cm |
| Weight | 20 g |
| Shipping Width | 9 cm |
| Shipping Depth | 11.5 cm |
| Shipping Height | 3.1 cm |
| Shipping Weight | 50 g |
| Service & Support | Limited warranty - lifetime |
Features - StarTech.com - 10057H-ST
More Details
Product Code
V934593
EAN Code
0065030885225
Manufacturer
StarTech.com
