StarTech.com Universal Laptop Docking Station / USB-C & USB 3.0 2x4K 60W PD / Docking station / USB-C / 2 x HDMI, 2 x DP / GigE / United Kingdom, Europe | DK30C2DPPDUE
StarTech.com Universal Laptop Docking Station / USB-C & USB 3.0 2x4K 60W PD / Docking station / USB-C / 2 x HDMI, 2 x DP / GigE / United Kingdom, Europe | DK30C2DPPDUE
Description
Transform your laptop into a dual-4K 60Hz workstation with this universal laptop docking station, for USB-C and USB 3.0 laptops. Connect to dual DisplayPort or HDMI monitors. Attach USB devices with four USB 3.0 ports. Plus, power your USB-C laptop with 60W Power Delivery.The USB-C and USB 3.0 docking station provides IT professionals with a convenient one-dock solution for offices using different laptop brands and operating systems. The dock works with Dell, HP, Lenovo, MacBook and most other laptops.The dual-4K docking station connects your laptop to Ultra HD DisplayPort or HDMI monitors: 2x 4K DisplayPort up to 4096 x 2160p @ 60Hz; 2x 4K HDMI up to 4096 x 2160p @ 60Hz; 1x 4K DP + 1x 4K HDMI display @ 60Hz.Connect to a single 5K display using two DP ports.Using a single cable, the dock powers and charges your laptop as you work with 60W PD, using the 135W power adapter.For fast setup right out of the box, the combo cable (USB-C with attached USB-A adapter) lets you connect any laptop. The dock has mounting holes for workstation mounting (bracket not included).Connect your devices with four USB 3.0 ports: 1x USB-C and 3x USB-A. Fast-charge your USB-C or USB-A smartphone. The dock provides a GbE port (PXE Boot support) and 3.5 mm 4-position headset audio jack. It also includes a security lock slot (K-slot) to protect against theft.
Product Specification
| Product Type | Docking station |
| Width | 22 cm |
| Depth | 8 cm |
| Height | 3 cm |
| Weight | 280 g |
| Enclosure Colour | Black, space grey |
| Localisation | United Kingdom, Europe |
| Max Resolution Details | 4096 x 2160 - 60 Hz |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, USB 1.1, USB 2.0, USB 3.0 |
| Interfaces | 1 x USB 3.1 Gen 1with Power Delivery - 9 pin USB Type A ¦ 2 x USB 3.1 Gen 1with Power Delivery - 24 pin USB-C ¦ 2 x display / video - 20 pin DisplayPort ¦ 2 x display / video - 19 pin HDMI Type A ¦ 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x USB 3.1 Gen 1 - 9 pin USB Type A ¦ 1 x headphone/microphone combo jack - mini-phone 3.5 mm |
| Cables Included | 1 x USB-C cable - external - 1 m |
| Features | Security lock slot (cable lock sold separately), dual monitor support, Preboot Execution Environment (PXE) support, full duplex support, DisplayPort Alt Mode, 60W power delivery |
| Security Slot Type | Kensington security slot |
| Compliant Standards | FCC, RoHS, USB Battery Charging Specification Rev. 1.2, DisplayPort 1.2, UASP (USB Attached SCSI Protocol), USB Power Delivery 3.0 |
| Power Device | Power adapter |
| Voltage Required | AC 120/230 V |
| OS Required | Microsoft Windows 7 / 8 / 8.1 / 10, Apple MacOS X 10.11 - 10.12, Google Chrome OS 55 or later, Apple MacOS X 10.14 |
| Service & Support | Limited warranty - 3 years |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
