StarTech.com USB C Multiport Adapter, USB-C to 4K HDMI or VGA Display/Video/Monitor with 100W Power Delivery Pass-through, 10Gbps USB Hub, MicroSD, Ethernet, USB 3.1 Gen 2 Type-C Mini Dock / Works w/ Thunderbolt 3 (CDP2HVGUASPD) / Docking | CDP2HVGUASPD
Product Features
- Connect a 4K HDMI or 1080p VGA monitor
For maximum productivity, connect your USB-C or Thunderbolt 3 laptop to a 4K 30Hz monitor, using this USB-C to 4K HDMI / 1080p VGA multiport adapter. You can also connect to an HDMI projector or TV in a boardroom or other meeting space, to deliver presentations on a shared screen. - Presentation mode switch
When you turn on this switch, the USB-C to HDMI adapter prevents your computer from launching its screen saver, going to sleep, or entering power save mode while presenting. Plus, the built-in MicroSD card reader can be used as external storage - ideal for storing & delivering presentations at boardroom/conference room meetings. - 100W Power Delivery 3.0 passthrough
The USB-C adapter lets you power and charge your USB-C laptop during a presentation or while you're working, with a USB-C Power Delivery port. Even if your laptop has only a single USB-C port available, you can keep your laptop powered. Device reserves 15 watts, avoiding video flicker, device dropouts and power overdraw which is commonly seen in other hubs with less reliable power distribution. - Add downstream USB-A & USB-C ports
This USB-C multiport adapter offers a USB 3.1 Gen 2 Type-A port (10Gbps), and a USB-C 3.1 Gen 2 port that can be used for power delivery charging, or if power delivery is not required, can be used as a 10Gbps data port for connecting USB-C peripherals. - MicroSD 4.0 Card Reader
This USB-C multiport adapter features a memory card slot, providing fast read and write access for microSD memory cards through USB 3.0. It's ideal for transferring photos, videos or presentations from your SD cards to your USB-C enabled laptop or tablet.
Special Features
- 7-in-1 functionality
- Presentation mode switch
- Reliable performance
- Portable & durable
- Wide compatibility
- Connectivity tools
Product Specification
Product Type | Docking station |
Width | 12.5 cm |
Depth | 6.8 cm |
Height | 1.6 cm |
Weight | 124.3 g |
Enclosure Colour | Grey, black |
Video | Video |
Max Resolution Details | 4096 x 2160 - 30 Hz (HDMI only) ¦ 1920 x 1080 - 60 Hz (VGA only) |
Networking | Networking |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
Compliant Standards | IEEE 802.3u, IEEE 802.3i, IEEE 802.3ab, USB 3.1 Gen 2 |
Expansion / Connectivity | Expansion / Connectivity |
Expansion Slots | 1 (total) / 1 (free) x microSD |
Interfaces | 1 x display / video - VGA - 15 pin HD D-Sub (HD-15) without pin 9 ¦ 1 x display / video - HDMI - 19 pin HDMI Type A ¦ 1 x USB-C 3.1 Gen 2 with Power Delivery (85 W) - 10 pin USB-C ¦ 1 x USB 3.1 Gen 2 with Battery Charging 1.2 - 9 pin USB Type A ¦ 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 |
Miscellaneous | Miscellaneous |
Input Device | microSD card reader |
Cables Included | 1 x USB-C cable - integrated - 13 cm |
Features | Wake on LAN, LED indicator, Preboot Execution Environment (PXE) support, Presentation Mode, aluminium/plastic enclosure, 100W power delivery (pass-through) |
Compliant Standards | FCC, RoHS, USB Battery Charging Specification Rev. 1.2, USB Power Delivery 3.0 |
System Requirements | System Requirements |
OS Required | Apple MacOS X 10.9 - 10.12, Apple macOS 11.0, Apple MacOS X 10.14 - 10.15, Apple macOS Monterey 12.0, Microsoft Windows 7 / 8 / 8.1 / 10 / 11 |
Manufacturer Warranty | Manufacturer Warranty |
Service & Support | Limited warranty - 3 years |
Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
Shipping Width | 14.2 cm |
Shipping Depth | 17 cm |
Shipping Height | 3 cm |
Shipping Weight | 138.3 g |
Environmental Parameters | Environmental Parameters |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 70 °C |
