Synology SA3400D - NAS server - 12 bays - rack-mountable - SAS - RAID 0, 1, 5, 6, 10, JBOD, RAID F1, 5 hot spare, 6 hot spare, 10 hot spare, 1 hot spare, F1 hot spare - RAM 16 GB - Gigabit Ethernet / 10 Gigabit Ethernet - iSCSI support - 2U | SA3400D
Please sign in so that we can notify you about a reply
Product Features
- Built-in high availability
Keep file sharing services, block storage, backups, and other office applications online with automatic minute-level failover. Defend against operational disruptions with two independent and hot-swappable controllers operating in an active-passive configuration. - Made for demanding environments
The SA3400D is engineered to provide outstanding performance in both NAS and SAN storage roles. Its throughput and random I/O performance support efficient SMB and NFS file serving as well as a range of iSCSI and Fiber Channel block storage applications. - Consolidate your data infrastructure
Manage, protect, and share data with versatile business solutions. Empower team collaboration, sandbox applications, and provide VM storage on a unified platform. - Flexible options to meet changing needs
Flexibly scale storage capacity, optimize I/O performance, and meet different network needs with a range of expansion options.
Special Fetures
- Built-in high availability
- Made for demanding environments
- Consolidate your data infrastructure
- Flexible options to meet changing needs
Product Specification
| Device Type | NAS server |
| Host Connectivity | Gigabit Ethernet / 10 Gigabit Ethernet |
| Enclosure Type | Rack-mountable - 2U |
| Total Storage Capacity | 0 GB |
| Storage Capacity Details | Single volume size: 108 TB |
| Max Supported Capacity | 576 TB |
| Installed Devices / Modules Qty | 0 (installed) / 12 (max) |
| Width | 48.2 cm |
| Depth | 72.4 cm |
| Height | 8.8 cm |
| Weight | 19.7 kg () |
| Built-in Devices | Led panel |
| Localisation | English, German, French, Italian, Spanish, Danish, Swedish, Dutch, Russian, Polish, Hungarian, Brazilian Portuguese, Portuguese, Turkish, Czech, Thai, Japanese, Korean, Chinese (traditional), Chinese (simplified) |
| Processor / Memory | |
| Processors Installed | 2 x Intel Xeon D-1541 2.1 GHz |
| Number of Cores | 8-core |
| Max Supported Qty | 2 |
| Max Turbo Speed | 2.7 GHz |
| RAM | 16 GB (installed) / 128 GB (supported) - DDR4 |
| Features | ECC |
| Storage Controller | |
| Type | 2 x RAID |
| Interface Type | SAS |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD, RAID F1, RAID 5 hot spare, RAID 6 hot spare, RAID 10 hot spare, RAID 1 hot spare, RAID F1 hot spare |
| Networking | |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE, 10GbE |
| Remote Management Protocol | SNMP, LDAP |
| Network Services Compatibility | Apple File Protocol (AFP), Server Message Block (SMB), FTP, Network File System (NFS), Web-based Distributed Authoring and Versioning (WebDAV), Server Message Block 2.0 (SMB 2.0), Server Message Block 3.0 (SMB 3.0), Network File System v3 (NFS v3), Network File System v4 (NFS v4), Network File System v4.1 (NFS v4.1), HTTP, HTTPS, Calendaring Extensions to WebDAV (CalDAV) |
| Performance | Maximum number of volume: 64 <br /> Maximum concurrent connections: 1200 <br /> Local group account: 512 <br /> Local user account: 16000 <br /> Maximum number of shared folders: 512 <br /> Maximum number of shared folders syncing tasks: 32 <br /> Hybrid share folder number: 30 <br /> Syslog: 3000 events per second |
| Features | EXT4 file system, B-tree file system (Btrfs), SSD read-write cache, SSD trim, RAID Group, RAID migration, NFS Kerberos authentication, Access Control List (ACL) support, data & folder backup, entire system backup, High Availability, OpenStack compatible, hardware encryption, VPN Server |
| Encryption Algorithm | AES-NI |
| Security DVR | |
| IP Cameras Supported | 100 |
| Compression Format | H.264, H.265 |
| Image Resolution | 1280x720, 1920x1080, 2048x1536, 2591x1944, 3840x2160 |
| Expansion / Connectivity | |
| Expansion Bays | 12 (total) / 12 (free) x hot-swap - 2.5" / 3.5" |
| Expansion Slots | 2 (total) / 2 (free) x PCI Express 3.0 x8 <br /> 8 (total) / 6 (free) x DIMM 288-pin |
| Interfaces | 4 x Ethernet 1000Base-T - RJ-45 <br /> 2 x Ethernet 10Gb - RJ-45 <br /> 2 x serial (management) - DB-9 <br /> 2 x expansion port |
| Miscellaneous | |
| Features | For 19" server cabinets, built-in 4 x 60 mm cooling fans, easy replacement system fan, power recovery, Citrix Ready, VMware Ready, reset button |
| Compliant Standards | FCC, BSMI, VCCI, UKCA, EAC, KC, RoHS, CCC, RCM |
| Included Accessories | Accessory pack, 2 x power cables |
| Power | |
| Power Device | Internal power supply |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 257.78 Watt |
| Power Provided | 500 Watt |
| Software / System Requirements | |
| Software Included | McAfee AntiVirus (Trial), Synology Central Management System |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 5 - 95% RH |
| Sound Emission | 51.3 dBA |
Features - Synology - SA3400D
More Details
Product Code
07:21231140
EAN Code
4711174725212
Manufacturer
Synology
