Teltonika OTD140 / - router / - WWAN 2-port switch / 1GbE / 3G, 4G, 2G / pole-mountable, surface-mountable | OTD140000000
Please sign in so that we can notify you about a reply
Product Features
- Robust security
Equipped with a comprehensive suite of encryption algorithms including 128-bit AES, 256-bit AES, and more, this router ensures your data remains secure and private. Its support for various authentication methods like RADIUS, TACACS+, and X.509 certificates further enhances network security, making it a suitable choice for sensitive environments. - Versatile connectivity
This router supports a wide range of cellular bands and protocols, including 4G LTE, ensuring reliable and fast Internet access across different regions. With dual Ethernet ports featuring PoE, it offers flexible wired connections, while the dual internal antennas promote robust wireless connectivity. - High performance
Powered by a MediaTek MIPS 24Kec processor with a clock speed of 580 MHz and equipped with 128 MB of DDR3 SDRAM, this router delivers exceptional performance for data-intensive applications. Its ability to handle up to 150 Mbps transfer rates makes it suitable for a variety of online activities. - Durable design
Designed for outdoor use with an IP55 compliant plastic housing, this router is built to withstand harsh environmental conditions. Its pole-mountable and surface-mountable form factors offer versatile installation options, ensuring reliable operation in any setting. - Advanced networking features
Featuring VPN support, firewall, and advanced routing protocols like BGP and OSPFv2, this router is equipped to manage complex networks. Its support for remote management protocols and network transport protocols ensures seamless integration and control over your network infrastructure.
Special Features
- Supports a wide range of encryption algorithms for enhanced security
- 4G LTE support across multiple bands for global connectivity
- 150 Mbps max transfer rate for high-speed Internet access
- IP55 compliant and suitable for outdoor installation
- Features VPN support and advanced routing protocols for comprehensive network management
Product Specification
| Device Type | Router - 2-port switch (integrated) |
| Enclosure Type | Pole-mountable, surface-mountable |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Network / Transport Protocol | NTP, ICMP/IP, PPPoE, ARP, SMTP, FTP, DHCP, DNS, SFTP, HTTP, HTTPs, IPv4, IPv6, UDP, TCP |
| Routing Protocol | RIP-1, RIP-2, BGP, EIGRP, VRRP, NHRP, OSPFv2 |
| Remote Management Protocol | SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, SSH-2, CLI, TR-069, JSON-RPC, Modbus, MQTT, SMNP, SMPP |
| Encryption Algorithm | DES, RC2, CAST5, 128-bit AES, 192-bit AES, 256-bit AES, 256-bit AES-GCM, 128-bit AES-GCM, AES-OFB, DESX |
| Authentication Method | RADIUS, X.509 certificates, TACACS+ |
| Features | WOL, SMS alert, plastic housing, reset button, DNP3 outstation, SQM, DLMS support, outdoor |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3af, IEEE 802.11e, IEEE 802.3at, IEEE 802.3az, UPnP, IP55, EAC, RCM, TLS, SSL, UKCA, UCRF |
| Processor | 1 x MediaTek MIPS 24Kec 580 MHz |
| RAM | 128 MB DDR3 SDRAM |
| Flash Memory | 16 MB |
| Built-in Devices | Dual internal aerials |
| Status Indicators | Signal strength, connection status, Ethernet link/activity |
| Communications | Communications |
| Type | Wireless cellular modem |
| Mobile Communication Protocol | 4G LTE |
| Generation | 3G, 4G, 2G |
| Cellular Band | LTE B3, LTE B7, LTE B20, LTE B1, LTE B5, LTE B28, LTE B8, LTE B40, LTE B41, LTE B38 |
| Max Transfer Rate | 150 Mbps |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | LAN: 2 x 10Base-T/100Base-TX (PoE) - RJ-45 |
| Expansion Slots | 2 (total) / 2 (free) x Mini-SIM |
| Power | Power |
| Power Device | External power adapter - 21 Watt |
| Miscellaneous | Miscellaneous |
| Included Accessories | Mounting bracket |
| Software / System Requirements | Software / System Requirements |
| OS Provided | RutOS |
| Dimensions & Weight | Dimensions & Weight |
| Width | 11 cm |
| Depth | 23.5 cm |
| Height | 4.93 cm |
| Weight | 855 g |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 75 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
Features - Teltonika - OTD140000000
More Details
Product Code
07:135055
EAN Code
4779027312927
Manufacturer
Teltonika
