Product Specification
| Device Type | Wireless router - 3-port switch (integrated) |
| Enclosure Type | DIN rail mountable |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, RS-232, IEEE 802.11b, IEEE 802.11g, RS-485, IEEE 802.11n |
| Frequency Band | 2.4 GHz |
| Capacity | Simultaneous connections: 100 |
| Network / Transport Protocol | PPTP, NTP, PPPoE, ARP, FTP, DHCP, DNS, L2TPv3, SFTP, IPv4, IPv6, Telnet, WireGuard, OpenVPN, UDP, TCP |
| Routing Protocol | RIP-1, RIP-2, BGP, EIGRP, VRRP, NHRP, OSPFv2 |
| Remote Management Protocol | SNMP 1, SNMP 2, SNMP 3, HTTP, HTTPS, SSH, SSH-2, TR-069, SMTP, ICMP, MQTT, BACnet, Kinesis, SMNP, SMPP |
| Encryption Algorithm | DES, CAST5, SSL, TLS, PEAP, TKIP, AES-CCMP, WPA2-PSK, WPA2-Enterprise, IKEv2, WEP, 256-bit AES-CBC, 128-bit AES-CBC, 192-bit AES-CBC, IKEv1, WPA3-SAE, WPA3-EAP, DESX |
| Authentication Method | RADIUS, X.509 certificates, Radio Service Set ID (SSID), TACACS+ |
| Features | Load balancing, VLAN support, wake on LAN (WOL), auto-uplink (auto MDI/MDI-X), MAC address filtering, Access Point operational mode, DDos attack prevention, Quality of Service (QoS), IPSec NAT-Traversal (NAT-T), port forwarding, DHCP relay, SNMP trap, GRE tunneling, static routing, Firmware Over-the-Air (FOTA), Captive Portal, passive PoE supported, Web Filtering, Pre-Shared Key (PSK), policy based routing, Fast Roaming, Modbus compatible, black list, white list, bridge mode, automated failover, Teltonika Remote Management System (RMS), Stealth Mode, Received Signal Strength Indication (RSSI) support, RADIUS Server, SSHFS support, band management, auto APN, client separation, Auto Cipher modes, mobile quota control, port scan prevention, GPS/GLONASS/Galileo/BeiDou/QZSS support, Unstructured Supplementary Service Data (USSD) support, DNP3 outstation, Networked Transport of RTCM via Internet Protocol (NTRIP), Smart Queue Management (SQM), DLMS support |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.11e, UPnP, IEEE 802.11r, CB, E Mark, EN 62311, IP30, EN 61000-4-2:2009, RCM, EN 300 328, EN 61000-4-6:2014, EN 61000-4-4:2012, EN 301 908-1, EN 301 908-2, EN 301 908-13, EN 301 489-1 V2.2.3, UKCA, IEC 62368-1:2018, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 61000-4-3:2020, EN 61000-4-5:2014+A1:2017, EN IEC 61000-4-11:2020, EN IEC 61000-3-2:2019+A1:2021, EN 301 489-19 V2.2.0, EN 301 489-17 V3.2.4, EN 301 489-52 V1.2.1, EN 61000-3-3:2013+A1:2019+A2:2021 |
| Processor | 1 x MediaTek MIPS 24Kec 580 MHz |
| RAM | 128 MB DDR2 SDRAM |
| Flash Memory | 16 MB |
| Built-in Devices | GNSS receiver |
| Status Indicators | Power, signal strength, connection status, Ethernet link/activity |
| Communications | Communications |
| Type | Wireless cellular modem |
| Mobile Communication Protocol | FDD LTE, TDD LTE |
| Generation | 3G, 4G, 2G |
| Cellular Band | LTE B3, LTE B7, LTE B20, LTE B1, LTE B28, LTE B8, LTE B40, LTE B41, LTE B38 |
| Max Transfer Rate | 150 Mbps |
| IP Telephony | IP Telephony |
| VoIP Protocols | H.323, SIP |
| Internet of Things (IoT) | Internet of Things (IoT) |
| Internet of Things (IoT) Compatible | Yes |
| Platform | Clouds of Things, ThingWorx, Cumulocity, Azure IoT Hub |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | WAN: 1 x 10Base-T/100Base-TX - RJ-45 ¦ LAN: 3 x 10Base-T/100Base-TX - RJ-45 ¦ Serial: 1 x RS-232 - 9 pin D-Sub (DB-9) ¦ Serial: 1 x RS-485 ¦ USB 2.0: 1 x 4 pin USB Type A ¦ Antenna: 2 x SMA - LTE ¦ Antenna: 2 x RP-SMA - Wi-Fi ¦ Antenna: 1 x SMA - GNSS aerial ¦ Input / output |
| Expansion Slots | 2 (total) / 2 (free) x Mini-SIM |
| Aerial | Aerial |
| Aerial | External detachable |
| Antenna Qty | 5 |
| Power | Power |
| Power Device | External power adapter - 9 Watt |
| Miscellaneous | Miscellaneous |
| Included Accessories | 2 x WiFi aerials, GNSS aerial, 2 x LTE aerials, I/O connector, SIM card adapter kit, RS-485 connector, power adapter (EU) |
| Cables Included | 1 x network cable - 1.5 m |
| Localisation | Thailand, Middle East, Africa, Europe (excluding Belarus, Russia) |
| Software / System Requirements | Software / System Requirements |
| OS Provided | RutOS |
| Dimensions & Weight | Dimensions & Weight |
| Width | 10.95 cm |
| Depth | 10 cm |
| Height | 5 cm |
| Weight | 295 g |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 75 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
Features - Teltonika - RUT906
More Details
Product Code
07:135398
EAN Code
4779051840830
Manufacturer
Teltonika
