Teltonika RUTX50 / Wireless router / WWAN / GigE, DNP3 / 3G, 4G, 5G / DIN rail mountable, surface-mountable | TRB500000000
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Wireless router |
| Enclosure Type | DIN rail mountable, surface-mountable |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, DNP3 |
| Capacity | IPSec VPN tunnels: 5 |
| Network / Transport Protocol | TCP/IP, PPTP, UDP/IP, NTP, ICMP/IP, IPSec, PPPoE, SMTP, DHCP, DNS, L2TPv3, DDNS, HTTP, HTTPs, IPv4, IPv6, WireGuard |
| Remote Management Protocol | SNMP 1, SNMP 2, SNMP, SNMP 3, HTTP, HTTPS, SSH, CLI, TR-069, JSON-RPC, Modbus, MQTT, Kinesis |
| Encryption Algorithm | DES, Triple DES, RC2, CAST5, TLS, SSL 3.0, MODBUS, IKEv2, 256-bit AES-CBC, 128-bit AES-CBC, 192-bit AES-CBC, IKEv1 |
| Authentication Method | X.509 certificates |
| Features | NAT support, VLAN support, wake on LAN (WOL), auto-uplink (auto MDI/MDI-X), MAC address filtering, DDos attack prevention, IPSec NAT-Traversal (NAT-T), Dynamic Multipoint VPN (DMVPN), port forwarding, reset button, SNMP trap, GRE tunneling, Firmware Over-the-Air (FOTA), SMS remote control, Web Filtering, Pre-Shared Key (PSK), gateway mode, black list, white list, bridge mode, Access Control Service (ACS), Point-to-Point Protocol (PPP), OpenVPN client, OpenVPN server, Teltonika Remote Management System (RMS), aluminium housing, 4x4 MIMO technology, Received Signal Strength Indication (RSSI) support, SSHFS support, band management, auto APN, digital certificates, mobile quota control, port scan prevention, SSTP client instance support |
| Compliant Standards | IP30 |
| Processor | 1 x ARM Cortex-A7 1.5 GHz |
| RAM | 256 MB |
| Flash Memory | 512 MB |
| Status Indicators | Power, signal strength, LAN, connection status |
| Communications | Communications |
| Type | Wireless cellular modem |
| Mobile Communication Protocol | GSM, FDD LTE, TDD LTE, 5G NR |
| Generation | 3G, 4G, 5G |
| Cellular Band | LTE B3, LTE B7, LTE B20, LTE B1, LTE B5, LTE B28, LTE B8, LTE B40, LTE B41, LTE B38, LTE B42, LTE B43, 5G n78, 5G n1, 5G n3, 5G n5, 5G n7, 5G n8, 5G n20, 5G n28, 5G n40, 5G n41, 5G n77, 5G n38 |
| Max Transfer Rate | 3.3 Gbps |
| Internet of Things (IoT) | Internet of Things (IoT) |
| Internet of Things (IoT) Compatible | Yes |
| Platform | Azure, Clouds of Things, ThingWorx, Cumulocity |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ USB: 1 x Micro-USB Type B ¦ 1 x DI/DO ¦ 1 x DI ¦ Antenna: 4 x SMA |
| Expansion Slots | 1 (total) / 1 (free) x Mini-SIM |
| Aerial | Aerial |
| Aerial | External detachable |
| Antenna Qty | 4 |
| Power | Power |
| Power Device | External power adapter - 9 Watt |
| Miscellaneous | Miscellaneous |
| Included Accessories | SIM card adapter kit, grounding screw, 4 x cellular aerials |
| Cables Included | 1 x micro-USB cable - 80 cm ¦ 1 x network cable |
| Localisation | Middle East, Africa, Brazil, Oceania, Europe (excluding Belarus, Russia) |
| Software / System Requirements | Software / System Requirements |
| OS Provided | RutOS |
| Software Included | ZeroTier VPN |
| Dimensions & Weight | Dimensions & Weight |
| Width | 10 cm |
| Depth | 9.34 cm |
| Height | 3 cm |
| Weight | 241 g |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 75 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
Features - Teltonika - TRB500
More Details
Product Code
07:127512
EAN Code
4779051840236
Manufacturer
Teltonika
