Teltonika TAP200 / Radio access point / 1GbE / Wi-Fi 5 / 2.4 GHz, 5 GHz / with PoE injector / for P/N: PR2LA15B, PR322EU7 | TAP200000000
TAP200000000
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Special Features
- Wi-Fi 5: Wave-2 802.11 b/g/n/ac Dual Band Wi-Fi
- RJ45 and PoE-in: supporting speeds of up to 1000 Mbps and PoE-in functionality
- Resilient and easy to install: UV-stabilized housing for lasting color with a mounting bracket for quick setup
Product Specification
| Device Type | Radio access point |
| Width | 15.8 cm |
| Depth | 3 cm |
| Height | 15.8 cm |
| Weight | 190 g |
| Bundled with | PoE injector |
| Processor / Memory / Storage | Processor / Memory / Storage |
| Processors Installed | 1 x MediaTek MIPS 1004Kc 800 MHz |
| Max Supported Qty | 1 |
| RAM | 256 MB DDR3 SDRAM |
| Flash Memory | 16 MB |
| Networking | Networking |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2 (draft 5.0) |
| Network / Transport Protocol | TCP/IP, UDP/IP, ICMP/IP, ARP, DHCP, HTTP, HTTPs, IPv4, IPv6 |
| Remote Management Protocol | HTTP, HTTPS, SSH, SSH-2, JSON-RPC, SMNP |
| Frequency Band | 2.4 GHz, 5 GHz |
| Capacity | Concurrent connections: up to 100 |
| Status Indicators | Power |
| Features | VLAN support, MAC address filtering, firmware upgradable, event log, hidden SSID, plastic housing, reset button, DHCP client, system log, UV stabilised enclosure, isolate mode, Teltonika Remote Management System (RMS), Auto Cipher modes, command-line interface (CLI) management, trouble shooting, kernel log |
| Encryption Algorithm | SSL, TLS, TKIP, WPA-PSK, AES-CCMP, WPA2-PSK, WPA2-EAP, Opportunistic Wireless Encryption (OWE), WPA3-SAE, WPA3-EAP |
| Authentication Method | Secure Shell (SSH) |
| Compliant Standards | IEEE 802.3af, IEEE 802.11r |
| Aerial | Aerial |
| Antenna | Internal |
| Antenna Qty | 4 |
| Directivity | Omni-directional |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x network - RJ-45 |
| Miscellaneous | Miscellaneous |
| Included Accessories | Mounting bracket |
| Compliant Standards | CB, IC, FCC, WEEE, IP30, EAC, EN 61000-4-2:2009, RCM, EN 61000-4-6:2014, IEC/EN 61000-4-3, EN 300 440 V2.2.1, EN 300 328 V2.2.2, EN 61000-4-4:2012, EN 301 489-1 V2.2.3, UKCA, IEC 62368-1:2018, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 61000-4-5:2014+A1:2017, EN IEC 61000-4-11:2020, EN IEC 62311:2020, EN IEC 62368-1:2020+A11:2020, EN IEC 61000-3-2:2019+A1:2021, UCRF, EN 301 489-17 V3.2.4, EN 61000-3-3:2013+A1:2019+A2:2021, EN 300 893 V2.1.1 |
| Power | Power |
| Power Over Ethernet (PoE) Supported | PoE Class 1 |
| Power Device | Power injector |
| Voltage Required | DC 44 - 57 V |
| Power Provided | 15 Watt |
| Software / System Requirements | Software / System Requirements |
| OS Provided | RutOS |
| Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
| Shipping Width | 35.5 cm |
| Shipping Depth | 17.5 cm |
| Shipping Height | 6 cm |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 75 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Compatibility Information | Compatibility Information |
| Designed For | P/N: PR2LA15B, PR322EU7 |
