Thermaltake SMART W3 700W - Power supply (internal) - ATX12V 3.1/ EPS12V - 80 PLUS - AC 100-240 V - 700 Watt - active PFC - black | PS-SPW-0700NNFAWE-1
Please sign in so that we can notify you about a reply
Product Features
- Efficient cooling
Equipped with a 120 mm fluid dynamic bearing cooling fan, this power supply ensures efficient heat dissipation, maintaining optimal performance even under high load conditions. - Reliable power delivery
With a single 12V rail design and 700 W of power, it provides a stable and reliable power supply to all components, supporting a wide range of PC builds. - Advanced protection features
Incorporates multiple protection features including overcurrent, overheat, overpower, overvoltage, short-circuit, and undervoltage correction, safeguarding your components from potential damage. - Modular cable management
The modular cable management system allows for a clean and organized build, improving airflow and aesthetics inside the case. - High compatibility
Complies with ATX12V 3.1/ EPS12V specifications and supports PC/Server power supply compatibility, ensuring broad compatibility with most motherboards and cases on the market.
Special Fetures
- 120 mm fluid dynamic bearing cooling fan for efficient heat dissipation
- 700 W of stable and reliable power supply
- Overcurrent, overheat, overpower, overvoltage, short-circuit, and undervoltage correction for comprehensive protection
- Modular cable management for a clean and organized build
- Compliant with ATX12V 3.1/ EPS12V specifications for broad motherboard and case compatibility
Product Specification
| Device Type | Power supply - active Power Factor Correction (PFC) - internal |
| Specification Compliance | ATX12V 3.1/ EPS12V |
| PSU Form Factor | ATX |
| Colour | Black |
| Power Device | |
| Input Voltage | AC 100-240 V |
| Frequency Required | 50 - 60 Hz |
| Power Output Connectors Details | 1 x power 24 pin ATX with detachable 4 pin section <br /> 2 x power 8 pin +12V with detachable 4 pin section <br /> 2 x 8 pin PCI Express power with detachable 2 pin section <br /> 4 x 4 PIN internal power <br /> 4 x 15 pin Serial ATA power |
| Output Voltage | +3.3, +5, ±12 V, +5Vsb V |
| Power Capacity | 700 Watt |
| Output Current | +3.3V - 18 A <br /> +5V - 18 A <br /> +12V - 58.33 A <br /> -12V - 0.3 A <br /> +5VSB - 3 A |
| 80 PLUS Certification | 80 PLUS |
| Miscellaneous | |
| MTBF | 100,000 hours |
| Cooling System | 120 mm fan |
| Features | Overheat protection, over current protection, over voltage protection, overpower protection, short-circuit protection, single 12V rail, DC-DC technology, fluid dynamic bearing cooling fan, undervoltage correction, Intel C6/C7 Sleep State compatible |
| Compliant Standards | CB, FCC, ICES, cTUVus |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Environmental Parameters | |
| Min Operating Temperature | 5 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 20 - 85% (non-condensing) |
| Dimensions & Weight | |
| Width | 15 cm |
| Depth | 14 cm |
| Height | 8.6 cm |
Features - Thermaltake - PS-SPW-0700NNFAWE-1
More Details
Product Code
04:486417
EAN Code
4711475645424
Manufacturer
Thermaltake
