TP-Link PSM500-AC V1 - Power supply - hot-plug (plug-in module) - AC 100-240 V - 500 Watt - for P/N: SG6428XHP V1, SG6654XHP V1 | PSM500-AC
Please sign in so that we can notify you about a reply
Product Features
- Efficient power supply
The PSM500-AC V1 is designed to ensure your network hardware always has the power it needs, with a robust 500 W output. Its compatibility with a wide range of network hardware makes it a versatile choice for any setup. - Advanced protection features
Equipped with overcurrent, overvoltage, undervoltage, and short-circuit protection, the PSM500-AC V1 safeguards your equipment against a variety of electrical issues, ensuring a reliable and secure operation. - Optimal performance in varied environments
With an operating humidity range of 10 - 90% RH and temperature tolerance from 0 °C to 45 °C, this power supply maintains optimal performance in a wide range of environmental conditions, making it suitable for diverse operational needs.
Special Fetures
- 500 W power output ensures ample supply for network hardware
- LED indicator for real-time status monitoring
- Comprehensive protection against overcurrent, overvoltage, and more
- Supports a wide input voltage range of AC 100-240 V for global compatibility
- Designed for hot-plug operation, facilitating easy installation and maintenance
Product Specification
| Device Type | Power supply - hot-plug - plug-in module |
| Power Device | |
| Input Voltage | AC 100-240 V |
| Frequency Required | 50/60 Hz |
| Output Voltage | 53.5 V |
| Power Capacity | 500 Watt |
| Miscellaneous | |
| Features | Over current protection, over voltage protection, undervoltage protection, short-circuit protection, LED indicator |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 10 - 90% RH (non-condensing) |
| Dimensions & Weight | |
| Width | 9.58 cm |
| Depth | 25.95 cm |
| Height | 4.01 cm |
| Compatibility Information | |
| Designed For | P/N: SG6428XHP V1, SG6654XHP V1 |
Features - TP-LINK - PSM500-AC
More Details
Product Code
CK22684
EAN Code
4895252502732
Manufacturer
TP-LINK
