TP-Link TL-SG1428PE / Switch / smart / 24 x 10/100/1000 (PoE+) + 2 x 10/100/1000 / rack-mountable / PoE+ (250 W) / AC 100 / 240 V | TL-SG1428PE
Please sign in so that we can notify you about a reply
Special Features
- 24 10/100/1000Mbps RJ45 PoE+ Ports Switch with 2 SFP Slots
- PoE power budget is up to 250 W, making it ideal for small to medium business surveillance systems
- Priority Mode helps to guarantee the quality of sensitive application like video monitoring
- PoE Auto Recovery enables system self-healing to guarantee the stable operation of PoE-connected devices
- QoS is for smooth internet-surfing experience and IGMP Snooping is capable of optimizing traffic for IPTV
- Intelligent power management can protect the switch from overload
Product Specification
| Device Type | Switch - 28 ports - smart |
| Enclosure Type | Rack-mountable 1U |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 (PoE+) + 2 x 10/100/1000 |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 250 W |
| Performance | Switching capacity: 56 Gbps ¦ Forwarding performance: 41.7 Mpps |
| Capacity | Packet buffer size: 4.1 Mbit |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 9KB |
| Routing Protocol | IGMPv2, IGMP, IGMPv3 |
| Features | Auto-negotiation, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, store and forward, Quality of Service (QoS), Cable Diagnostics Function, loop prevention, security lock slot (cable lock sold separately), DiffServ Code Point (DSCP) support, 2 fans, Storm Control, Static Link Aggregation, DSCP prioritisation |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 801.1p, IEEE 802.3at |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 24 x 10/100/1000 Base-T RJ-45 PoE+ - 30 W ¦ 2 x 10/100/1000 Base-T RJ-45 |
| Expansion Slots | 2 (total) / 2 (free) x SFP (mini-GBIC) |
| Power | Power |
| Power Device | Internal power supply |
| Voltage Required | AC 100 - 240 V (50/60 Hz) |
| Power Consumption Operational | 304.7 Watt |
| Miscellaneous | Miscellaneous |
| Included Accessories | Rubber feet |
| Rack Mounting Kit | Included |
| Compliant Standards | FCC, RoHS |
| Dimensions & Weight | Dimensions & Weight |
| Width | 44 cm |
| Depth | 22 cm |
| Height | 4.4 cm |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 5 - 90% (non-condensing) |
Features - TP-LINK - TL-SG1428PE(UN)
General
24-Port
More Details
Product Code
04:352974
EAN Code
6935364072209
Manufacturer
TP-LINK
