TP-Link JetStream TL-SG2428P / Switch / smart / 24 x 10/100/1000 (PoE+) + 4 x SFP / rack-mountable / PoE+ (250 W) | TL-SG2428P
Please sign in so that we can notify you about a reply
TP-Link JetStream TL-SG2428P / Switch / smart / 24 x 10/100/1000 (PoE+) + 4 x SFP / rack-mountable / PoE+ (250 W) | TL-SG2428P
Special Features
- Full Gigabit ports provide high-speed connections
- Centralized management - cloud access and Omada app for ultra convenience and easy management
- Static Routing - helps route internal traffic for more efficient use of network resources
- Robust security strategies - IP-MAC-Port binding, ACL, port security, Dos defend, storm control, DHCP snooping, radius authentication
- Optimize voice and video applications - L2/L3/L4 QoS and IGMP snooping
Product Specification
| Device Type | Switch - 24 ports - smart |
| Enclosure Type | Rack-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 (PoE+) + 4 x SFP |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 250 W |
| Performance | Switching capacity: 56 Gbps ¦ Forwarding performance: 41.7 Mpps |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 9KB |
| Routing Protocol | IGMPv2, IGMP, IGMPv3, MLDv2, MLD |
| Remote Management Protocol | SNMP 1, RMON 1, RMON 2, SNMP, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, TFTP, SSH, DHCP, IPv4, IPv6 |
| Encryption Algorithm | SSL, SSL 3.0, TLS 1.2 |
| Authentication Method | Secure Shell (SSH), RADIUS, PAP, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP), EAP-TLS, EAP-TTLS |
| Features | Flow control, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), MLD snooping, bandwidth control, Device Link Detection Protocol (DLDP) support, 512KB packet buffer, Neighbor Discovery Protocol (NDP), Class of Service (CoS), Strict Priority (SP), Generic VLAN Registration Protocol (GVRP), 2 fans, Storm Control, Bridge protocol data unit (BPDU), Link Aggregation, Authentication, Authorization and Accounting (AAA), Voice VLAN, IP/Mac/Port Binding (IPMB), Zero-touch provisioning (ZTP), Weighted Round Robin (WRR), loopback detection, Maximum Likelihood Detection (MLD), DSCP prioritisation |
| Compliant Standards | IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at, IEEE 802.3az |
| Interfaces | 24 x 1000Base-T RJ-45 PoE+ ¦ 4 x Gigabit LAN SFP |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 308.6 Watt |
| Included Accessories | Rubber feet |
| Rack Mounting Kit | Included |
| Compliant Standards | FCC, RoHS |
| Width | 44 cm |
| Depth | 22 cm |
| Height | 4.4 cm |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 5 - 90% (non-condensing) |
Features - TP-LINK - SG2428P
General
24-Port
More Details
Product Code
CJ89198
EAN Code
6935364030650
Manufacturer
TP-LINK
