TP-Link Omada SX3832MPP V1 / Switch / L2+ / Managed / 24 x 100/1000/2.5G/5G/10GBase-T (PoE++) + 8 x 10Gb Ethernet SFP+ / rack-mountable / PoE++ (770 W) | SX3832MPP
Please sign in so that we can notify you about a reply
Product Features
- Robust switching capacity
The TP-Link Omada SX3832MPP V1 offers a switching capacity of 640 Gbps, ensuring smooth transmissions even under heavy workloads. - Flexible power over Ethernet
With a PoE budget of 770 W and support for 24 PoE++ ports, this switch facilitates seamless device connectivity and power management. - Enhanced security features
Features such as port security, DHCP snooping, and an array of authentication methods help safeguard the network from unauthorized access. - Multiple remote management protocols
The switch supports a wide variety of protocols including SNMP, Telnet, and SSH, which simplifies network monitoring and management. - Robust environmental resistance
Designed to operate within a temperature range of -5°C to 45°C and with high humidity capabilities, this switch is built for resilience.
Special Features
- 640 Gbps switching capacity for high-speed performance
- 770 W PoE budget supports multiple devices
- Support for VLAN, IGMP snooping, and port security
- Robust build with metal housing for durability
- Remote management through various protocols
Product Specification
| Device Type | Switch - 32 ports - L2+ - Managed |
| Enclosure Type | Rack-mountable |
| Subtype | 10 Gigabit Ethernet |
| Ports | 24 x 100/1000/2.5G/5G/10GBase-T (PoE++) + 8 x 10Gb Ethernet SFP+ |
| Power Over Ethernet (PoE) | PoE++ |
| PoE Budget | 770 W |
| Performance | Switching capacity: 640 Gbps Packet forwarding rate: 240 Mpps Packet buffer size: 24 Mbit |
| Capacity | IPv4 interfaces: 128 IPv6 interfaces: 128 Static routes: 48 Static ARP entries: 128 ARP entries: 510 Maximum aggregation groups: 8 Ports per aggregation group: 8 Layer 2 multicast filtering profiles: 256 Layer 2 multicast filtering entries per profile: 16 IGMP groups: 4000 VLAN groups: 4000 MAC VLAN address entries: 30 VLAN templates: 16 Priority queues: 8 IP MAC port binding entries: 512 IPv6 MAC port binding entries: 512 Port security entries: 64 |
| MAC Address Table Size | 32K entries |
| Jumbo Frame Support | 9KB |
| Routing Protocol | Static IP routing, STP, RSTP, MSTP, IGMP, IGMPv2, IGMPv3, MLD, MLDv2, L2PT, PPPoE |
| Remote Management Protocol | CLI, RMON, OAM, DHCP, TCP/IP, UDP, IPv4, IPv6, HTTP, HTTPS, SNMP 1, SNMP 2c, SNMP 3, RMON 1, RMON 2, RMON 3, RMON 9, BOOTP, ICMP, MIB, Syslog, NTP, TFTP, SSH, Telnet, SSH-2, RSTP |
| Encryption Algorithm | SSL 3.0, TLS 1.2 |
| Authentication Method | RADIUS, TACACS+, Secure Shell (SSH), Secure Shell v.2 (SSH2) |
| Features | Cloud managed, VLAN support, ACL support, QoS, IGMP snooping, DDM, ERPS, metal housing, SDN Architecture, ZTP, flow control, fast PoE, perpetual PoE, store and forward, 6KV Surge protection, firmware upgradable, automatic device discovery, schedule reboot, ARP support, proxy ARP, DHCP server, DHCP relay, Link Aggregation, BPDU Filter, loop protection, BPDU protection, loopback detection, port mirroring, fast leave, MVR, MLD snooping, tagged VLAN, GVRP, VPN support, Voice VLAN, CoS, DSCP support, SP, WRR, bandwidth control, rate limit, MAC and IP-based ACLs support, IPMB, DHCP snooping, ARP inspection, DHCPv6 snooping, ND detection, ND snooping, IP source guard, DoS attack prevention, DHCP filtering, Port Security, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Unknown Storm Control, 802.1x authentication, MAB, Guest VLAN, AAA, port isolation, DLDP support, sFlow, LLDP-MED, Cable Diagnostics Function, SNTP support, system log, EEE, path MTU discovery |
| Compliant Standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3an, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3ae, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 802.3az |
| RAM | 512 MB |
| Flash Memory | 32 MB |
| Built-in Devices | 4 x fans |
| Status Indicators | Power, system, PoE max, link/activity, fan |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 24 x 100/1000/2.5G/5G/10GBase-T RJ-45 PoE++ - 90 W 8 x 1/10GBase-X SFP+ 1 x console RJ-45 1 x console USB Type-C |
| Power | Power |
| Power Device | Internal power supply |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Consumption Stand by | 57.7 Watt |
| Miscellaneous | Miscellaneous |
| Included Accessories | Rubber feet |
| Cables Included | 1 x console cable |
| Rack Mounting Kit | Included |
| MTBF | 315,002 hours |
| Compliant Standards | FCC, RoHS |
| Software / System Requirements | Software / System Requirements |
| Software Included | Omada Controller |
| OS Required | Microsoft Windows 98SE/2000/NT/XP/Vista/7/8/8.1/10/11, Apple MacOS, Novell NetWare, UNIX, Linux |
| Dimensions & Weight | Dimensions & Weight |
| Width | 44 cm |
| Depth | 33 cm |
| Height | 4.4 cm |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -5 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 10 - 90% RH (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 5 - 90% RH (non-condensing) |
Features - TP-LINK - SX3832MPP
General
24-Port
More Details
Product Code
CN27611
EAN Code
8885020622676
Manufacturer
TP-LINK
