TP-Link TL-PA7017P V4 / Powerline adapter / GigE, HomePlug AV (HPAV), HomePlug AV (HPAV) 2.0, IEEE 1901 / wall-pluggable | TL-PA7017P
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Powerline adapter |
| Enclosure Type | Wall-pluggable |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, HomePlug AV (HPAV), HomePlug AV (HPAV) 2.0, IEEE 1901 |
| Data Transfer Rate | 1000 Mbps |
| Max Range Indoors | 300 m |
| Encryption Algorithm | 128-bit AES |
| Features | Reset button, power-saving mode, pair button |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, HomePlug AV, HomePlug AV 2.0, IEEE 1901, Plug and Play, RoHS |
| Status Indicators | Power, LAN, powerline |
| Line Properties | Line Properties |
| Line Coding Format | OFDM |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x HomePlug AV 2.0 |
| Power | Power |
| Power Device | Internal power supply |
| Voltage Required | (50 Hz) |
| Power Consumption Operational | 2.7 Watt |
| Miscellaneous | Miscellaneous |
| Cables Included | 1 x network cable |
| Software / System Requirements | Software / System Requirements |
| OS Required | Apple MacOS, Linux, Microsoft Windows 2000 / XP / 2003 / Vista / 7 / 8 / 8.1 / 10 |
| Dimensions & Weight | Dimensions & Weight |
| Width | 5.8 cm |
| Depth | 4.2 cm |
| Height | 9.5 cm |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
Features - TP-LINK - TL-PA7017P(EU)
More Details
Product Code
04:348357
EAN Code
6935364010812
Manufacturer
TP-LINK
