TP-Link SafeStream TL-R605 / Router / 4-port switch / GigE | TL-R605
Product Features
- Omada SDN
As the gateway that seamlessly integrates into the Omada Software Defined Networking (SDN) platform, TL-R605 allows for remote and centralized management, anywhere, anytime. Standalone management via the Web UI or app is also available to maximize convenience. - Hassle-free centralized cloud management
100% centralized cloud management of whole network from different sites - all controlled from a single interface anywhere, anytime. - Up to four WAN Gigabit ports to optimize bandwidth usage
Three freely interchangeable ports that can be set to either WAN or LAN allow the router to support up to four WAN ports to satisfy various internet access requirements through one device. The multi-WAN Load Balancing function distributes data streams according to the bandwidth proportion of every WAN port to raise the utilization rate of multi-line broadband. - Internet access management strategy
Standardize users' online behavior and easily specify the internet access rights and strategies of employee via IP/MAC/URL Filtering and Access Control List (ACL). Captive Portal authentication facilitates network resource control by capturing, authenticating, and classifying user access. Appropriate network resources can also be allocated for particular users or guests.
Special Features
- Integrated into Omada SDN
- Centralized management
- Five Gigabit ports
- Up to 4 WAN ports
- Highly secure VPN
- Abundant security features
Product Specification
Device Type | Router - 4-port switch (integrated) |
Enclosure Type | Desktop |
Connectivity Technology | Wired |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
Performance | VPN throughput (IPSec): 41.5 Mbps |
Capacity | IPSec VPN tunnels: 20 ¦ PPTP VPN tunnels: 16 ¦ L2TP VPN tunnels: 16 ¦ Concurrent sessions: 25000 |
Network / Transport Protocol | TCP/IP, PPTP, L2TP, NTP, ICMP/IP, IPSec, PPPoE, FTP, DHCP, DNS, SIPS, HTTP, HTTPs |
Routing Protocol | IGMPv2, static IP routing, IGMPv3 |
Remote Management Protocol | SNMP |
Encryption Algorithm | DES, Triple DES, MD5, IKE, SHA-1, 128-bit AES, 192-bit AES, 256-bit AES |
Features | NAT support, Stateful Packet Inspection (SPI), VPN passthrough, IP address filtering, firmware upgradable, LAN-to-LAN bridging, Access Control List (ACL) support, Dead Peer Detection (DPD), virtual server support, DHCP server, reset button, bandwidth control, port triggering, Stateful Packet Inspection Firewall (SPIF), IP-MAC binding, DHCP client, Diagnostic Function, Ping of Death, IGMP proxy, Captive Portal, DHCP reservation, system log, ARP inspection, port filtering, Perfect Forward Secrecy (PFS), Zero-touch provisioning (ZTP), Denial of Service (DoS) protection, DMZ support, DynDNS, schedule reboot |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x, UPnP, FCC, RoHS |
RAM | 128 MB |
Flash Memory | 16 MB |
Status Indicators | Power, system, WAN, LAN |
IP Telephony | IP Telephony |
VoIP Protocols | H.323 |
Expansion / Connectivity | Expansion / Connectivity |
Interfaces | WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN / LAN: 3 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 |
Power | Power |
Power Device | External power adapter |
Voltage Required | DC 9 V |
Electric Current Required | 0.85 A |
Software / System Requirements | Software / System Requirements |
OS Required | UNIX, Apple MacOS, Novell NetWare, Linux, Microsoft Windows 98SE/2000/NT/ME/XP/Vista/7 |
Dimensions & Weight | Dimensions & Weight |
Width | 15.8 cm |
Depth | 10.1 cm |
Height | 2.5 cm |
Environmental Parameters | Environmental Parameters |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 40 °C |
Humidity Range Operating | 10 - 90% (non-condensing) |
