TP-Link TL-SL1226P / Switch / unmanaged / 24 x 10/100 (PoE+) + 2 x 10/100/1000 + 2 x combo Gigabit SFP / desktop, rack-mountable / PoE+ (250 W) | TL-SL1226P
Description
TP-Link's new PoE/PoE+ switches with all 10/100 Mbps RJ45 ports supporting the PoE+ standard provides a simple way to expand the wired network while transferring power over the same Ethernet cable at the same time. With up to 30 W per port TL-SL1226P can power more high-powered devices such as Access Points, IP Cameras, IP Phones and so on. Moreover, with innovative Extend Mode, devices can get PoE power supply and data transmission from a distance of 250 m. Priority mode ensures high priority for port 1 - 8, which guarantees the quality of sensitive applications. TL-SL1226P supports Isolation Mode that divides traffic for ports 1 - 24 for higher security and performance.
TP-Link TL-SL1226P Switch unmanaged 24 x 10100
Special Features
- 24x PoE+ 10/100 Mbps RJ45 ports, 2x Gigabit RJ45 ports, and 2x combo Gigabit SFP slots
- High PoE power budget with up to 30 W for each PoE port and 250 W for all PoE ports
- Up to 250 m data and power PoE transmission range under Extend Mode, ideal for surveillance system
- Priority Mode ensures high priority of ports 1 - 8 to guarantees the quality of sensitive applications like video monitor
- Isolation Mode allows one-click client traffic separation for higher security and performance
- Plug and play, with no configuration and installation needed
Product Specification
| Device Type | Switch - 26 ports - unmanaged |
| Enclosure Type | Desktop, rack-mountable 1U |
| Subtype | Fast Ethernet |
| Ports | 24 x 10/100 (PoE+) + 2 x 10/100/1000 + 2 x combo Gigabit SFP |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 250 W |
| Performance | Switching capacity: 8.8 Gbps ¦ Packet forwarding rate: 6.54 Mpps |
| Capacity | Packet buffer size: 4.1 Mbit |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 10KB |
| Features | Flow control, power over Ethernet (PoE), auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward, PoE+, 2 fans, MAC address learning, MAC address aging, priority mode, extend mode, security slot (Kensington security lock compatible) |
| Compliant Standards | IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at |
| Status Indicators | Power, 100M device connected, 1000M device connected, PoE, link/activity, PoE max |
| Interfaces | 24 x 100Base-TX RJ-45 PoE+ - 30 W ¦ 2 x 1000Base-T RJ-45 ¦ 2 x 1000Base-X SFP |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 294 Watt |
| Rack Mounting Kit | Included |
| Compliant Standards | Plug and Play, FCC, RoHS |
| Width | 44 cm |
| Depth | 18 cm |
| Height | 4.4 cm |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 5 - 90% (non-condensing) |
Features - TP-LINK - TL-SL1226P
General
24-Port
More Details
Product Code
Z001275
EAN Code
6935364089443
Manufacturer
TP-LINK
