TP-Link VIGI NVR1016H V1 - NVR - 16 channels - 0 - networked - rack-mountable | VIGI NVR1016H
Please sign in so that we can notify you about a reply
Product Features
- 24/7 continuous recording
Stores up to 10 TB of footage from connected cameras to secure your data for quick, convenient access. - 16-channel real-time live view
Sharp image definition up to 8MP and a 16-channel display ensures you capture every detail, from every angle. - Remote monitoring
A dedicated VIGI app is developed for remote monitoring, providing ease and convenience. - Smart video coding by H.265+
Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality. - Two-way audio
With voice intercom support, carry two-way conversations while watching your feed from anywhere. - 80Mbps video access bandwidth
High video access bandwidth ensures your NVR manages more cameras with high resolution. Based on laboratory testing using VIGI cameras, VIGI NVR can manage up to 16 x 4MP cameras.
Special Fetures
- 24/7 continuous recording: stores up to 10 TB of footage from connected cameras to secure your data for quick, convenient access
- 16-channel real-time live view: sharp image definition up to 8MP and a 16-channel display ensures you capture every detail, from every angle
- Quick lookup and playback: find the target footage easily by date, event types, and tags
- Remote monitoring: dedicated VIGI app is developed for remote monitoring, providing ease and convenience
- H.265+: without using any extra bandwidth, your camera transmits compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality
- Two-way audio: with voice intercom support, carry two-way conversations while watching your feed from anywhere
Product Specification
| Device Type | NVR - rack-mountable |
| Video Channels | 16 |
| Image Resolution | 1280x720, 1920x1080, 1280x1024, 1440x900, 1680x1024 |
| Compression Format | H.264, H.265, H.264+, H.265+ |
| Security DVR | |
| Networked | Yes |
| Features | 80Mbps Incoming Bandwidth, 60Mbps Outgoing Bandwidth |
| Hard Drive | |
| Quantity Installed | 0 |
| Quantity Supported | 1 |
| Interface | Serial ATA |
| Video Server | |
| Features | Two-way audio support |
| Networking | |
| Network Interfaces | Ethernet 10Base-T/100Base-TX |
| Supported Protocols | DHCP, DNS, NTP, TCP/IP, UPnP |
| Features | ONVIF support |
| Connections | |
| Video Input Ports | RJ-45 x 1 |
| Video Output Ports | HDMI x 1, VGA x 1 |
| Audio Input Ports | RCA x 1 |
| Audio Output Ports | RCA x 1 |
| Network Port | 10/100Base-T |
| Other Ports | USB 2.0 x 2 |
| Power | |
| Voltage | 12 V |
| Power Consumption | 4.25 Watt |
| Power Consumption Details | Without HDD |
| Dimensions & Weight | |
| Width | 24.62 cm |
| Depth | 14.82 cm |
| Height | 4.5 cm |
| Weight | 578.5 g |
| Environmental Parameters | |
| Min Operating Temperature | -10 °C |
| Max Operating Temperature | 55 °C |
Features - TP-LINK - VIGI NVR1016H(UN)
More Details
Product Code
04:381408
EAN Code
4897098683293
Manufacturer
TP-LINK
