TRENDnet TC-P12C6AS / Patch panel / wall mountable / RJ-45 X 12 / 0.5U | TC-P12C6
Please sign in so that we can notify you about a reply
Product Features
- Cat6A performance
Cat6A cabling allows performance of up to 10Gbps speeds over Cat6A Ethernet cables. - Shielded housing design
Sturdy metal housing design protects against EMI/RFI noise for a more stable connection. - Cable management
Integrated cable management cover plate with convenient cable separation for better organization and reduced cable clutter.
Special Features
- 10G-Ready 12-port patch panel
- Cat6A patch panels deliver a steady connection to copper gigabit & 10G switches
- Shielded design to eliminate EMI and crosstalk
- Compatible with Cat5e, Cat6 and Cat6A cabling
- Wall mountable metal housing
- Color-coded labeling for T568A and T568B wiring schemes
- 110 IDC type terminal blocks (use 110 or Krone type tool)
- Use with TRENDnet TC-PDT Punch Down Tool (sold separately)
- Supports ANSI/EIA/TIA 568-B.2-1, ISO/IEC 11801, and EN50173-1
- 90° angle type
- Operating temperature: -25° - 50° C (-13° - 122° F)
Product Specification
| Product Type | Patch panel - CAT 6a |
| Placing / Mounting | Wall mountable |
| Package Content | Screws, cable ties |
| Product Material | SPCC steel |
| Height (Rack Units) | 0.5U |
| Width | 22 cm |
| Depth | 9.7 cm |
| Height | 2.5 cm |
| Weight | 506 g |
| Cabling & Wiring | Cabling & Wiring |
| Port Qty | 12 ports |
| Termination Type | 110 type termination, IDC |
| Technology | Shielded twisted pair (STP) |
| Features | Gold-plated connectors, colour-coded |
| Connector Provided | 12 x RJ-45 female |
| Miscellaneous | Miscellaneous |
| Features | Integrated cable management, 10GbE compatible, 90° angled, metal housing |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 2 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -25 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 90% (non-condensing) |
Features - Trendnet - TC-P12C6
More Details
Product Code
04:190515
EAN Code
0710931401356
Manufacturer
Trendnet
