Product Specification
| Device Type | Switch - 24 ports |
| Enclosure Type | Rack-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 |
| Performance | Switching capacity: 48 Gbps ¦ Forwarding rate (64-byte packets): 18.6 Mpps |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 9KB |
| Features | Half duplex mode, full duplex mode, fanless |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x |
| RAM | 512 KB |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 24 x 1000Base-T RJ-45 |
| Power | Power |
| Power Device | Internal power supply |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 9.5 Watt |
| Miscellaneous | Miscellaneous |
| MTBF | 674,176 hours |
| Compliant Standards | FCC, ETL |
| Dimensions & Weight | Dimensions & Weight |
| Width | 2.5 cm |
| Depth | 16 cm |
| Height | 10.9 cm |
| Weight | 414 g |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 0 - 90% (non-condensing) |
Features - Trendnet - TEG-S25
General
24-Port
More Details
Product Code
CE24791
EAN Code
0710931140873
Manufacturer
Trendnet
