TRENDnet TEW 821DAP AC1200 Dual Band PoE Access Point / Radio access point / Wi-Fi 5 / 2.4 GHz, 5 GHz | TEW-821DAP
Please sign in so that we can notify you about a reply
Product Features
- Access point flexibility
Concurrent 867 Mbps Wi-Fi AC and 300 Mbps Wi-Fi N combined with AP, Client, WDS, and Repeater modes support multiple applications. - Centralized management
The included Windows based software controller manages multiple TEW-821DAPs and reduces Wi-Fi management and troubleshooting time. - Easy installation
Saves remote location installation time and costs with Gigabit Power over Ethernet (PoE) support and a convenient mounting plate.
Special Features
- Multi-language
- Power over Ethernet (PoE)
- Concurrent dual band
- Multi-mode support
- Software controller
- Gigabit port
- Wireless coverage
- Encrypted wireless
- Band steering
- Wi-Fi traffic shaping
- Multiple SSIDs
- Targeted beamforming
- IPv6
- Low profile
- LED control
- Mounting plate
Product Specification
| Device Type | Radio access point |
| Width | 18.7 cm |
| Depth | 18.7 cm |
| Height | 4.6 cm |
| Weight | 456 g |
| Enclosure Colour | Off-white |
| Networking | Networking |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 867 Mbps |
| Line Coding Format | DBPSK, DQPSK, CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, OFDM |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Spread Spectrum Method | DSSS |
| Remote Management Protocol | SNMP 1, SNMP 3, CLI |
| Frequency Band | 2.4 GHz, 5 GHz |
| Capacity | Maximum number of configured SSIDs: 16 |
| Features | DHCP support, repeating mode, MAC address filtering, IPv6 support, Wireless Distribution System (WDS) support, firmware upgradable, Spanning Tree Protocol (STP) support, Wi-Fi Multimedia (WMM) support, event log, Quality of Service (QoS), reset button, beamforming technology |
| Encryption Algorithm | WPA, WPA2, WPA-PSK, WPA2-PSK, WEP |
| Authentication Method | Radio Service Set ID (SSID) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.3x, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Aerial | Aerial |
| Antenna Qty | 4 |
| Gain Level | 4 dBi |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x 1000Base-T - RJ-45 |
| Miscellaneous | Miscellaneous |
| Included Accessories | Mounting brackets |
| Cables Included | 1 x network cable - 1.5 m |
| Compliant Standards | FCC |
| Power | Power |
| Power Device | External power adapter |
| Power Consumption Operational | 9.6 Watt |
| Software / System Requirements | Software / System Requirements |
| OS Required | Microsoft Windows Vista / XP / 7 / 8 / 8.1 |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 0 - 95% (non-condensing) |
Features - Trendnet - TEW-821DAP
More Details
Product Code
04:190243
EAN Code
0710931130577
Manufacturer
Trendnet
