TRENDnet TFC 110S20D3I / Fibre media converter / 100Mb LAN / 10Base-T, 100Base-FX, 100Base-TX / SC single-mode / RJ-45 / up to 20 km / 1310 (TX) / 1550 (RX) nm | TFC-110S20D3i
Please sign in so that we can notify you about a reply
Special Features
- Port level SNMP management support
- SC-type dual-wavelength single-mode fiber port
- 10/100Base-TX RJ-45 port
- Spans distances up to 20 km (12.4 miles)
- Functions as a standalone converter or with the TFC-1600 fiber chassis
Product Specification
| Device Type | Fibre media converter |
| Form Factor | External |
| Networking | Networking |
| Connectivity Technology | Wired |
| Cabling Type | 10Base-T, 100Base-FX, 100Base-TX |
| Data Link Protocol | 10Mb LAN, 100Mb LAN |
| Data Transfer Rate | 200 Mbps |
| Optical Wave Length | 1310 (TX) / 1550 (RX) nm |
| Remote Management Protocol | SNMP |
| Max Transfer Distance | 20 km |
| Status Indicators | Power, link/activity |
| Features | Auto-negotiation, half duplex mode, full duplex mode, Link Loss Return (LLR), Link Loss Carry Forward (LLCF), wall mountable |
| Compliant Standards | IEEE 802.3, IEEE 802.3u |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x Ethernet 100Base-FX - SC single-mode female ¦ 1 x Ethernet 10Base-T/100Base-TX - RJ-45 female |
| Miscellaneous | Miscellaneous |
| Compliant Standards | FCC, RoHS |
| Power | Power |
| Power Device | External power adapter |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 2 Watt |
| Dimensions & Weight | Dimensions & Weight |
| Width | 12 cm |
| Depth | 8.8 cm |
| Height | 2.5 cm |
| Weight | 354 g |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 0 - 90% |
Features - Trendnet - TFC-110S20D3i
More Details
Product Code
04:190327
EAN Code
0710931504576
Manufacturer
Trendnet
