TRENDnet TI-G102 / Switch / unmanaged / 8 x 10/100/1000 + 2 x combo Gigabit SFP / DIN rail mountable, wall-mountable / DC power | TI-G102
Please sign in so that we can notify you about a reply
Product Features
- Gigabit speeds
Ten gigabit ports provide high-speed network connections to devices, and a 20 Gbps switching capacity allows data traffic to flow smoothly, reducing traffic bottlenecks. - Fault tolerance
Features dual redundant power inputs with output alarm relay.
Special Features
- 8 x Gigabit ports
- 2 x Gigabit RJ-45 / SFP shared ports
- 20Gbps switching capacity
- Hardened IP30 rated metal switch
- Includes DIN-rail and wall mounts
- Operating temperature range of -40° – 75°C (-40° – 167°F)
- Dual redundant power inputs with overload current protection
- Alarm output triggered by power failure
Product Specification
| Device Type | Switch - 10 ports - unmanaged |
| Enclosure Type | DIN rail mountable, wall-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 8 x 10/100/1000 + 2 x combo Gigabit SFP |
| Performance | Switching capacity: 20 Gbps ¦ Forwarding performance (64-byte packet size): 14.8 Mpps |
| MAC Address Table Size | 16K entries |
| Jumbo Frame Support | 10KB |
| Features | Auto-negotiation, store and forward, half duplex mode, full duplex mode, 2MB packet buffer, 6KV ESD Protector, metal housing |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3x |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 10 x 1000Base-T RJ-45 ¦ 2 x SFP |
| Power | Power |
| Power Device | External power adapter |
| Installed Qty | 0 (installed) / 2 (max) |
| Power Redundancy | Yes |
| Voltage Required | DC 12 - 56 V |
| Power Consumption Operational | 5.76 Watt |
| Miscellaneous | Miscellaneous |
| Included Accessories | DIN-rail mounting kit, wall mounting kit, removable terminal block |
| MTBF | 510,400 hours |
| Compliant Standards | FCC, IP30, EN 60068-2-27, EN 60068-2-32, EN 60068-2-6 |
| Dimensions & Weight | Dimensions & Weight |
| Width | 15.5 cm |
| Depth | 12 cm |
| Height | 4.8 cm |
| Weight | 415 g |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 75 °C |
| Humidity Range Operating | 95% (non-condensing) |
Features - Trendnet - TI-G102
General
8-Port
More Details
Product Code
04:226339
EAN Code
0710931160925
Manufacturer
Trendnet
