Product Features
- 60 Watt power
Provides up to 60 Watts of power for PoE devices such as switches, network cameras, and access points. - Active PFC
The built-in active power factor controller helps eliminate unusable reactive power. - Overload protection
Overload, short circuit, over voltage, over temperature protection. - Passive cooling
Cooling by free air convection. - DIN-rail mount
IP30 rated metal enclosure with integrated DIN-rail mount. - LED indicator
LED indicator confirms power to the unit.
Special Features
- IP30 rated industrial power supply with integrated DIN-rail mount
- Built-in active PFC
- Short circuit, overload, over voltage, over temperature protection
- Wide operating temperature range
Product Specification
| Device Type | Power supply - DIN rail mountable |
| Power Device | Power Device |
| Input Voltage | AC 100-240 V |
| Frequency Required | 50/60 Hz |
| Output Voltage | 24 V |
| Power Capacity | 60 Watt |
| Miscellaneous | Miscellaneous |
| MTBF | 2,992,000 hours |
| Features | Over voltage protection, overload protection, short-circuit protection |
| Compliant Standards | TUV, EN55022, EN55024, CISPR 22, CB, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5, EN 61000-6-2, EN 61000-4-11, EN 61000-4-8, UL 60950-1, EN 60950-1, IEC 60068-2-6, UL 508, EN 55011, EN 61204-3, EN61000-3-2, EN61000-3-3 |
| TAA Compliant | Yes |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 1 year |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -20 °C |
| Max Operating Temperature | 70 °C |
| Humidity Range Operating | 0 - 90% (non-condensing) |
| Dimensions & Weight | Dimensions & Weight |
| Width | 4 cm |
| Depth | 10 cm |
| Height | 9 cm |
| Weight | 300 g |
| Compatibility Information | Compatibility Information |
| Designed For | TRENDnet TI-F11SFP, TI-G160i-M, TI-G50, TI-G62, TI-G80 |
Features - Trendnet - TI-M6024
More Details
Product Code
04:190440
EAN Code
0710931160376
Manufacturer
Trendnet
