TRENDnet TPE-TG51g / Switch / unmanaged / 4 x 10/100/1000 (PoE+) + 1 x 10/100/1000 / desktop, wall-mountable / PoE+ (60 W) | TPE-TG51G
Please sign in so that we can notify you about a reply
Product Features
- Port isolation
Ideal for surveillance networking applications, the DIP switch also enables port isolation on ports 1 - 4. - LED indicators
LED indicators on the long-range PoE switch convey port status. - PoE+ power
A 60W PoE power budget supplies up to four Power over Ethernet devices. - Gigabit Ethernet
Five Gigabit ports provide a 10Gbps switching capacity to support edge network installations.
Special Features
- 4 x Gigabit PoE+ ports
- 1 x Gigabit port
- 60W PoE power budget
- Extend PoE+ signal up to 200m (656 ft.) at 10Mbps
- DIP switch supports VLAN port isolation and QoS
- 10Gbps switching capacity
- Compact metal switch
- Wall mountable design
Product Specification
| Device Type | Switch - 5 ports - unmanaged |
| Enclosure Type | Desktop, wall-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 4 x 10/100/1000 (PoE+) + 1 x 10/100/1000 |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 60 W |
| Performance | Switching capacity: 10 Gbps ¦ Forwarding performance (64-byte packet size): 7.44 Mpps |
| MAC Address Table Size | 2K entries |
| Jumbo Frame Support | 9KB |
| Features | VLAN support, half duplex mode, full duplex mode, Quality of Service (QoS), 128KB packet buffer, rugged, built-in DIP switch, port isolation, Class of Service (CoS), metal housing |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3p, IEEE 802.3at |
| Status Indicators | Power, PoE, link/activity |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 4 x 1000Base-T RJ-45 PoE+ ¦ 1 x 1000Base-T RJ-45 |
| Power | Power |
| Power Device | External power adapter |
| Power Provided | 55 V - 1.3 A |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Electric Current Required | 2.5 A |
| Power Consumption Operational | 64.3 Watt |
| Miscellaneous | Miscellaneous |
| Compliant Standards | FCC, LVD |
| Dimensions & Weight | Dimensions & Weight |
| Width | 12.1 cm |
| Depth | 7.5 cm |
| Height | 2.6 cm |
| Weight | 246 g |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 0 - 90% (non-condensing) |
Features - Trendnet - TPE-TG51G
General
5-Port
More Details
Product Code
CB26444
EAN Code
0710931162080
Manufacturer
Trendnet
