TRENDnet TPE TG611 / Switch / 4 x 10/100/1000 (PoE+) + 1 x 10/100/1000 (uplink) + 1 x Gigabit SFP / desktop / PoE+ (65 W) | TPE-TG611
Please sign in so that we can notify you about a reply
Product Features
- PoE+ power
The small network switch with SFP support features a 65W total PoE power budget that supplies up to four power over Ethernet devices. - 6 Gigabit ports
Six Gigabit ports provide a full 12Gbps switching capacity to this small network switch with SFP support for edge network installations. - Compact design
With a compact and lightweight housing design, this compact switch is well-suited for desktop installations. Its fanless design is perfect for quiet environments that require silent operation.
Special Features
- Supports 100/1000Base-FX fiber SFP modules
- Reduces equipment cost by delivering data and power over existing network cables
- Compact wall-mountable metal housing
- Fanless design
Product Specification
| Device Type | Switch - 6 ports |
| Enclosure Type | Desktop |
| Subtype | Gigabit Ethernet |
| Ports | 4 x 10/100/1000 (PoE+) + 1 x 10/100/1000 (uplink) + 1 x Gigabit SFP |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 65 W |
| Performance | Switching capacity: 12 Gbps ¦ Forwarding performance (64-byte packet size): 8.292 Mpps ¦ Buffer memory: 128 KB |
| MAC Address Table Size | 2K entries |
| Jumbo Frame Support | 9KB |
| Features | Half duplex mode, full duplex mode, wall mountable, fanless, Class of Service (CoS) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at |
| Status Indicators | Port status |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 4 x 1000Base-T RJ-45 PoE+ ¦ 1 x 1000Base-T RJ-45 uplink ¦ 1 x Gigabit LAN SFP |
| Power | Power |
| Power Device | Internal power supply |
| Power Provided | 55 V - 1.3 A |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 71.5 Watt |
| Miscellaneous | Miscellaneous |
| MTBF | 1,401,356 hours |
| Compliant Standards | FCC |
| Dimensions & Weight | Dimensions & Weight |
| Width | 19.3 cm |
| Depth | 8.4 cm |
| Height | 2.6 cm |
| Weight | 456 g |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 0 - 90% (non-condensing) |
Features - Trendnet - TPE-TG611
More Details
Product Code
04:328560
EAN Code
0710931161670
Manufacturer
Trendnet
