TRENDnet TPE TPE-2840WS 28-Port Gigabit Web Smart PoE+ Switch / Switch / Managed / 4 x 10/100/1000 (PoE+) + 20 x 10/100/1000 (PoE) + 4 x SFP / desktop, rack-mountable / PoE+ (185 W) | TPE-2840WS
Please sign in so that we can notify you about a reply
Product Features
- Hardware design
Provides 4 x Gigabit PoE+ ports, 20 x Gigabit PoE ports, 4 x SFP slots, a PoE Power budget of 185 watts, and includes rackmount brackets. - Smart fan
Smart fan saves energy by varying fan speed and use based on cooling needs. - IPv6 ready
This switch supports IPv6 configuration and IPv6 neighbor discovery. - Traffic management
A broad range of network configurations are supported by: 802.3ad link aggregation, Asymmetric VLAN, 802.1Q VLAN, Voice VLAN, Private VLAN, Bandwidth Controls, GVRP, IGMP v1-v3, 802.1p Class of Service (CoS), Spanning Tree (STP, RSTP, and MSTP), and QoS queue scheduling. - Troubleshooting
Real time traffic comparison charts, error group charts, and a convenient cable diagnostic test aid in rapid troubleshooting. - Access controls
Features such as ACL, SSL, MAC/port filtering, Denial of Service controls, 802.1x, TACACS+, and RADIUS are compatible with layered network access controls.
Special Features
- 185 watt PoE budget
- 56 Gbps switching capacity
- Private/Voice VLAN, QoS, and bandwidth controls
- Smart fans reduce energy consumption
Product Specification
| Device Type | Switch - 28 ports - Managed |
| Enclosure Type | Desktop, rack-mountable 1U |
| Subtype | Gigabit Ethernet |
| Ports | 4 x 10/100/1000 (PoE+) + 20 x 10/100/1000 (PoE) + 4 x SFP |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 185 W |
| Performance | Switching capacity: 56 Gbps ¦ Forwarding performance (64-byte packet size): 41.7 Mpps |
| MAC Address Table Size | 16K entries |
| Routing Protocol | IGMPv2, IGMP, IGMPv3, static IPv6 routing |
| Remote Management Protocol | SNMP 1, RMON 1, SNMP 3, SNMP 2c, HTTP, HTTPS |
| Encryption Algorithm | TLS, SSL 3.0, SSL 2.0 |
| Authentication Method | RADIUS, TACACS+ |
| Features | DHCP support, VLAN support, Weighted Round Robin (WRR) queuing, IPv6 support, GREENnet technology, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Virtual Cable Test (VCT) technology, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Quality of Service (QoS), RADIUS support, reset button, Management Information Base (MIB), Dynamic VLAN Support (GVRP), Class of Service (CoS), tagged VLAN, Loopback, Denial of Service (DoS), Duplicated Address Detection, per port bandwidth control, DiffServ Code Point (DSCP) support, PoE overcurrent protection, PoE circuit sorting protection, 3 fans |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az |
| RAM | 1 MB |
| Status Indicators | Power, PoE, link/activity, SFP |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 4 x 1000Base-T RJ-45 PoE+ ¦ 20 x 1000Base-T RJ-45 PoE ¦ 4 x SFP |
| Power | Power |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 240.2 Watt |
| Miscellaneous | Miscellaneous |
| Rack Mounting Kit | Included |
| MTBF | 257,362 hours |
| Compliant Standards | UL 60950, FCC, RoHS, WEEE |
| Software / System Requirements | Software / System Requirements |
| Software Included | Drivers & Utilities |
| OS Required | Microsoft Windows Server 2003, Microsoft Windows Server 2008, Microsoft Windows Vista / XP / 7 / 8 / 8.1 |
| Dimensions & Weight | Dimensions & Weight |
| Width | 44 cm |
| Depth | 25 cm |
| Height | 4.445 cm |
| Weight | 3.8 kg |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -5 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 0 - 90% (non-condensing) |
Features - Trendnet - TPE-2840WS
General
8-Port
More Details
Product Code
04:190417
EAN Code
0710931160208
Manufacturer
Trendnet
