Ubiquiti airFiber 5 / Wireless bridge / AirFiber / AirFiber | AF-5
|
Description The high-isolation, dual-antenna design is ideal for robust performance in the harshest RF noise environments.The airFiber 5 is purpose-built for outdoor, PtP bridging and carrier-class network backhauls. Special Features
Product features
|
Product Specification
| Device Type | Wireless bridge |
| Width | 46.84 cm |
| Depth | 28.14 cm |
| Height | 93.84 cm |
| Weight | 16 kg |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 1.2 Gbps |
| Line Coding Format | 64 QAM, 256 QAM, QPSK, 16 QAM, 1024 QAM |
| Data Link Protocol | AirFiber |
| Frequency Band | 5 GHz |
| Max Range Open Space | 100 km |
| Status Indicators | Port transmission speed, power, link/activity |
| Features | Pole mountable, GPS sync compatible |
| Encryption Algorithm | 128-bit AES |
| Gain Level | 23 dBi |
| Interfaces | 1 x 1000Base-T (PoE) - RJ-45 ¦ 1 x management - RJ-45 ¦ 1 x auxiliary - RJ-12 |
| Included Accessories | PoE injector, pole mount |
| Compliant Standards | IC, FCC |
| Power Over Ethernet (PoE) Supported | PoE |
| Power Consumption Operational | 40 Watt |
| OS Provided | AirOS |
| Service & Support | Limited warranty - parts and labour - 1 year |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 55 °C |
Features - Ubiquiti - AF-5
More Details
Product Code
04:171374
EAN Code
0810354022067
Manufacturer
Ubiquiti
