Ubiquiti airFiber 60 LR / Wireless bridge / AirFiber / AirFiber | AF60-LR
Please sign in so that we can notify you about a reply
Special Features
- Low-interference 60 GHz Spectrum
- Integrated GPS
- Long range, up to 12 km
- Precision alignment mount included
- Quick setup using the UISP App via Bluetooth
Product Specification
| Device Type | Wireless bridge |
| Built-in Devices | GPS |
| Width | 41.3 cm |
| Depth | 36 cm |
| Height | 41.3 cm |
| Weight | 1.5 kg |
| Processor / Memory / Storage | Processor / Memory / Storage |
| Processors Installed | 1 x ARM Cortex-A7 |
| RAM | 256 GB DDR3 SDRAM |
| Networking | Networking |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 1.8 Gbps |
| Data Link Protocol | AirFiber |
| Frequency Band | 60 GHz |
| Max Range Open Space | 12 km |
| Status Indicators | Power, link/activity, GPS, 60 GHz |
| Features | Syslog support, passive PoE supported, NTP client, Point-to-Point (PtP) link mode, bridge mode, 24KV ESD Protector (air-gap discharge), 24KV ESD Protector (contact discharge), test Internet speed, Bluetooth management, Wave Technology |
| Encryption Algorithm | AES, WPA2-PSK |
| Aerial | Aerial |
| Gain Level | 43 dBi |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x 1000Base-T (PoE) - RJ-45 |
| Miscellaneous | Miscellaneous |
| Included Accessories | PoE injector, pole mount |
| Compliant Standards | IC, FCC |
| Power | Power |
| Power Over Ethernet (PoE) Supported | Passive PoE |
| Power Consumption Operational | 18 Watt |
| Software / System Requirements | Software / System Requirements |
| OS Provided | AirOS |
| Software Included | Ubiquiti ISP |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 60 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
Features - Ubiquiti - AF60-LR
More Details
Product Code
04:379273
EAN Code
0810010073563
Manufacturer
Ubiquiti
