Product Features
- Modular design
The antenna horn is interchangeable and helps with beam-shaping for specific deployment and environment needs. The IsoStation also gets maximum gain out of the smallest footprint. - Beam performance perfected
The IsoStation can use a variety of horn antenna sectors designed for increased co-location performance without sacrificing gain. Its unique beam performance and superb co-location characteristics allow for a higher density of sectors than traditional sector technology. - Improved noise immunity
IsoStation blocks or spatially filters out noise, so noise immunity is improved. This feature is especially important in an area crowded with other RF signals of the same or similar frequency.
Special Fetures
- Modular design
- Beam performance perfected
- Improved noise immunity
Product Specification
| Device Type | Wireless bridge |
| Width | 6.5 cm |
| Depth | 13.1 cm |
| Height | 13.1 cm |
| Weight | 408.2 g |
| Processor / Memory / Storage | |
| Processors Installed | 1 x MIPS 74KC |
| RAM | 64 MB DDR2 SDRAM |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Link Protocol | AirMax |
| Performance | Throughput: 100 Mbps |
| Status Indicators | Power |
| Features | Pole mountable, 24KV ESD Protector |
| Aerial | |
| Gain Level | 14 dBi |
| Expansion / Connectivity | |
| Interfaces | 1 x 1000Base-T (PoE) - RJ-45 |
| Miscellaneous | |
| Included Accessories | Pole mount |
| Compliant Standards | IC, FCC, RoHS |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE |
| Power Consumption Operational | 6.5 Watt |
| Environmental Parameters | |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 70 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
Features - Ubiquiti - IS-M5
More Details
Product Code
07:820381
EAN Code
0810354026744
Manufacturer
Ubiquiti
