Ubiquiti UniFi Dream Router / Wireless router / 4-port switch / GigE / 802.11a/b/g/n/ac/ax / Dual Band | UDR
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Wireless router - 4-port switch (integrated) |
| Enclosure Type | Desktop |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax |
| Frequency Band | 2.4 GHz / 5 GHz |
| Performance | Maximum data rate (2.4 GHz): 600 Mbps ¦ Maximum data rate (5 GHz): 2.4 Gbps |
| Capacity | BSSIDs per radio: 8 ¦ Number of concurrent clients: 300+ |
| Encryption Algorithm | WPA, WPA2, WPA-PSK, WPA-Enterprise, WEP, WPA3 |
| Features | VLAN support, firmware upgradable, reset button, microSD card slot, Advanced QoS, Guest Isolation, 4x4 MIMO technology, 32W PoE power budget |
| Compliant Standards | IEEE 802.1Q, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IC, FCC |
| Processor | 1 x 1.35 GHz |
| RAM | 2 GB |
| Built-in Devices | Status LCD |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | LAN: 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ LAN: 2 x 10Base-T/100Base-TX/1000Base-T (PoE) - RJ-45 ¦ WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 |
| Aerial | Aerial |
| Aerial | Internal |
| Antenna Qty | 1 |
| Power | Power |
| Power Device | Internal power supply - 50 Watt |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Dimensions & Weight | Dimensions & Weight |
| Width | 11 cm |
| Depth | 11 cm |
| Height | 18.413 cm |
| Weight | 1.15 kg |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -10 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
Features - Ubiquiti - UDR
More Details
Product Code
07:126842
EAN Code
0810010078261
Manufacturer
Ubiquiti
