Vertiv EDGE - UPS (rack-mountable / external) - AC 230 V - 1980 Watt - 2200 VA - USB - output connectors: 7 - 2U | EDGELI-2200IRT2U
Please sign in so that we can notify you about a reply
Special Fetures
- 0.9 output power factor delivers more usable power, savings space and cost
- High efficiency, up to 98% in line mode, to deliver energy savings
- Color graphic LCD display
- Flexible 2U rack/tower form factor
- Up to seven battery-backed outlets
- Programmable outlets to optimize battery runtime
- Hot-swappable user-replaceable internal batteries
- Input breaker device for additional protection to the load in worst case failures
- Remote emergency shut down capability via EPO port
- USB communications for UPS status monitoring and management
Product Specification
| Device Type | UPS - rack-mountable / external |
| Height (Rack Units) | 2U |
| Power Device | |
| UPS Technology | Line interactive |
| Input Voltage | AC 230 V |
| Input Connectors | 1 x power IEC 60320 C20 |
| Power Output Connectors Details | 6 x power IEC 60320 C13 <br /> 1 x power IEC 60320 C19 |
| Output Voltage | AC 200/208/220/230/240 V |
| Power Capacity | 1980 Watt / 2200 VA |
| Output Waveform | Sinewave |
| Circuit Protection | Circuit breaker |
| Efficiency | 98% line mode |
| Power Factor (PF) | 0.9 |
| Battery | |
| Technology | Lithium ion |
| Networking | |
| Remote Management Interface | USB |
| Expansion / Connectivity | |
| Interfaces | 1 x USB |
| Expansion Slots | 1 (total) / 1 (free) x Liebert IntelliSlot |
| Miscellaneous | |
| Features | Emergency power off, LCD display, programmable load outlets |
| Compliant Standards | CB, RoHS, REACH, EAC, RCM, UN38.3, UKCA |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Dimensions & Weight | |
| Width | 43.8 cm |
| Depth | 51 cm |
| Height | 8.6 cm |
| Weight | 17.5 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 56.5 cm |
| Shipping Depth | 70 cm |
| Shipping Height | 24 cm |
| Shipping Weight | 25.2 kg |
Features - Vertiv - EDGELI-2200IRT2U
More Details
Product Code
CD25944
EAN Code
0767041033816
Manufacturer
Vertiv
