Hanwha Vision WiseNet Q QNV-7022R / Network surveillance camera / dome / indoor, outdoor / dustproof / waterproof / vandal-proof / colour (Day&Night) / 4 MP / 2560 x 1440 / board mount / auto iris / fixed focal / audio / composite / LAN 10/10 | QNV-7022R
Please sign in so that we can notify you about a reply
Product Features
- Robust design
Built to withstand harsh environmental conditions, the Hanwha Vision WiseNet Q QNV-7022R features an IP66 rating for dust and water resistance, and an IK10 rating for impact protection, ensuring reliable performance in any setting. - Advanced imaging
Equipped with a 1/3" CMOS sensor and a wide range of capture resolutions up to 2560 x 1440, the camera delivers clear, high-quality video footage. Features such as Wide Dynamic Range (WDR) and Samsung Super Noise Reduction (SSNR) enhance image clarity in varied lighting conditions. - Intelligent surveillance
This network surveillance camera incorporates Intelligent Video Analysis (IVA), including intrusion detection and motion detection, providing precise monitoring and reducing false alarms. Its day and night functionality, complemented by infrared LEDs with a 25 m range, ensures effective surveillance around the clock. - Flexible connectivity
Supporting a variety of network protocols and equipped with Ethernet 10Base-T/100Base-TX interface, the Hanwha Vision WiseNet Q QNV-7022R offers versatile connectivity options for easy integration into existing systems. The camera's audio support and multiple video formats, including H.264 and H.265, allow for comprehensive surveillance solutions. - Durable and compliant
The camera is TAA-compliant, adhering to the requirements for government procurement. Its compliance with standards such as IEEE 802.1x and IEEE 802.3af underscores its reliability and security features, making it a trustworthy choice for a wide range of applications.
Special Features
- IP66 and IK10 rated for dust, water, and impact resistance
- 1/3" CMOS sensor with up to 2560 x 1440 resolution
- Infrared illumination up to 25 m for clear night vision
- Supports Intelligent Video Analysis (IVA) for enhanced security
- Compliant with multiple network protocols for easy integration
Product Specification
| Device Type | Network surveillance camera |
| Audio Support | Yes |
| Form Factor | Dome |
| Connectivity Technology | Wired |
| Width | 12.03 cm |
| Depth | 12.03 cm |
| Height | 9.17 cm |
| Weight | 510 g |
| Camera | Camera |
| Type | Colour - Day&Night - fixed - indoor, outdoor - dustproof / waterproof / vandal-proof |
| Digital Video Format | MJPEG, H.264, H.265 |
| Max Digital Video Resolution | 2560 x 1440 |
| Motion Detection | Yes |
| Minimum Illumination | 0.15 lux - colour - F1.6 - shutter 1/30 sec 0 lux - B&W - infrared LEDs on |
| Infrared LEDs | Yes |
| Infrared Distance | 25 m |
| Digital Video Capture Resolution | 1280 x 720, 720 x 480, 640 x 480, 1280 x 960, 320 x 240, 1024 x 768, 720 x 576, 1280 x 1024, 800 x 600, 1920 x 1080, 640 x 360, 2304 x 1296, 2560 x 1440, 800 x 448 |
| Frame Rate (max) | 15 frames per second |
| Features | Backlight Compensation (BLC), progressive scanning, Wide Dynamic Range (WDR), Motion Detection Technology, Privacy Mask Function, Intelligent Video Analysis (IVA), tamper-detection, Lens Distortion Correction, Variable Bitrate (VBR), Constant Bitrate (CBR), Multicast Streaming, auto gain control, auto white balance, Defocus Detection, ONVIF (Profile S) support, ONVIF (Profile G) support, Samsung Super Noise Reduction (SSNR), WiseStream Smart Codec |
| Image Sensor | Image Sensor |
| Type | 4 MP CMOS 1/3" |
| Lens Construction | Lens Construction |
| Type | Board mount - fixed focal |
| Focal Length | 4 mm |
| Lens Iris | F/1.6 auto iris (DC) |
| Horizontal Field of View (degree) | 78.2 |
| Vertical Field of View (degree) | 41.2 |
| Diagonal Field of View (degree) | 92 |
| Panning | Panning |
| Range (degree) | 0 to 350 |
| Tilting | Tilting |
| Range (degree) | 0 to 67 |
| Interfaces | Interfaces |
| Video | Composite video |
| Network Interface | Ethernet 10Base-T/100Base-TX |
| Network Protocols | DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, PPPoE, IGMP, SSL, QOS, PIM-SM |
| Alarm Inputs Qty | 1 |
| Alarm Outputs Qty | 1 |
| Expansion / Connectivity | Expansion / Connectivity |
| Ports | Composite video Audio line-in/microphone LAN/power - RJ-45 |
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| Miscellaneous | Miscellaneous |
| Compliant Standards | IK10, IP66, IEEE 802.3af, IEEE 802.1x, EN 62676-4 |
| Colour | White, RAL 9003 |
| Power | Power |
| Power Requirements | DC 12 V / PoE Class 3 |
| Power Device | 8.1 Watt |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -30 °C |
| Max Operating Temperature | 55 °C |
| Relative Humidity (operating) | 0 - 90% |
Features - Hanwha Techwin - QNV-7022R
More Details
Product Code
07:21246253
EAN Code
8801089202628
Manufacturer
Hanwha Techwin
