XPG PYLON - Power supply (internal) - ATX12V 2.52 - 80 PLUS Bronze - AC 90-264 V - 550 Watt - Europe | 75260122
Please sign in so that we can notify you about a reply
Product Features
- DC-to-DC circuit in BRONZE grade
XPG PYLON complies with Intel ATX Power Supply Design Guide's sleep mode function, featuring DC-to-DC 100% +12V Full Power in all PYLON series, ensuring that power delivery remains consistent, power-efficient, and capable of supporting mid to high-end graphic cards and CPUs. - 80 Plus Bronze certification
XPG PYLON is an 80 Plus Bronze certified power supply unit that guarantees energy efficiency at 20%, 50% and 100% of rated loads. XPG PYLON also complies with ErP 2014 Lot 3 Regulation, and it is designed for steady 24/7 Continuous Power system operation. - Cybenetics ETA and LAMBDA certified
XPG PYLON SERIES is certified by Cybenetics for its efficiency and noise level, scoring at the top of its category in both ETA and LAMBDA standards. - 120mm Fluid Dynamic Bearing (FDB) fan
The fan control of the built-in 120mm Fluid Dynamic Bearing (FDB) Fan starts at around 700 rpm (25°C ambient) and maintains its low fan speed until around 70% power load. The operating environment is kept quiet and efficient, and prolongs its life expectancy. - Main Japanese capacitor at 105°C
High quality 105°C Main Japanese Capacity in XPG PYLON Bronze Series ensures great durability and offer highest stability and reliability. - 8 industrial-level protections
XPG PYLON is designed for both efficiency and safety. Fundamental protections such as OPP, UVP, OVP, SCP, OTP and OCP are all included, as well as NLO and SIP which are found in mid to high-end PSU, offering one of the highest standards of stability and security in this category.
Special Fetures
- DC to DC converters
- 80PLUS BRONZE certified
- Continuous power for 24/7 system operation
- 120mm FDB silent-performance fan
- High current +12V rail system compatibility
- Main Japanese capacitor
- Multiple PCI-E 2.0 6+2 pin connectors
- Industrial-level protection OVP, OPP, SCP, OCP, UVP, OTP, NLO, SIP
- Complies with ErP 2014 Lot 3
Product Specification
| Device Type | Power supply - internal |
| Specification Compliance | ATX12V 2.52 |
| PSU Form Factor | ATX |
| Localisation | Europe |
| Power Device | |
| Input Voltage | AC 90-264 V |
| Frequency Required | 47 - 63 Hz |
| Power Output Connectors Details | 1 x power 24 pin ATX <br /> 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section <br /> 5 x 15 pin Serial ATA power <br /> 2 x 8 pin PCI Express power with detachable 2 pin section <br /> 2 x 4 PIN internal power <br /> 1 x 4 PIN mini-power connector |
| Power Capacity | 550 Watt |
| Power Factor (PF) | 0.99 |
| 80 PLUS Certification | 80 PLUS Bronze |
| Miscellaneous | |
| MTBF | 100,000 hours |
| Cooling System | 120 mm fan |
| Features | Over current protection, over voltage protection, overpower protection, undervoltage protection, short-circuit protection, no load operation protection, Surge & Inrush Protection (SIP) |
| Compliant Standards | TUV, BSMI, TUV S, CCC, EMC, FCC, RoHS, cTUVus, EAC, RCM, Energy-Related Products (ErP) Lot 3, CB 60950, CB 62368 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Dimensions & Weight | |
| Width | 15 cm |
| Depth | 14 cm |
| Height | 8.6 cm |
