Zebra DS2278-HC - Healthcare - barcode scanner - handheld - 2D imager - 762 mm / sec - decoded - Bluetooth | DS2278-HC0000BZZRW
Please sign in so that we can notify you about a reply
Product Features
- Purpose-built for healthcare
Your mission-critical operations deserve a specialist, not a general purpose scanner. With the DS2200-HC series, you get a scanner that's built for the job. Disinfectant-ready housing withstand regular sanitizing with popular disinfectants. A "do not disturb mode" enables clinicians to instantly know if a medication or wristband was properly scanned without disturbing a resting patient with a loud beep. - Easy to deploy and manage
Right out of the box, the scanner is configured for the healthcare applications you use everyday. The DS2200-HC series is designed for easy integration with your tablet-based EMR applications.
Special Fetures
- Purpose-built for healthcare
- Easy to deploy and manage
Product Specification
| Type | Barcode scanner - handheld |
| Colour | Healthcare white |
| Barcode | |
| Interface Type | Bluetooth |
| Minimum Bar Width | 4 mil |
| Scan Element Type | 2D imager |
| Sensor Resolution | 640 x 480 |
| Light Source Wave Length | 624 nm |
| Scan Mode | Single-pass |
| Scan Speed | 762 mm / sec |
| Skew (Degrees) | 65 |
| Pitch (Degrees) | 65 |
| Print Contrast Signal (PCS) | 15% |
| Decode Capability | Code 93, Industrial 2 of 5, Code 39, NW-7, GS1 DataBar, Italy Pharmacode, Codabar, Code 128, Code 11, UPC, PDF417, MSI-Plessey |
| TTL Decoding | Decoded |
| Connectivity Technology | Wireless |
| OK Notification | Beeper, LED indicator |
| Networking | |
| Wireless Connectivity | Bluetooth 4.0 |
| Miscellaneous | |
| Compliant Standards | EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-4-2, RoHS, FCC CFR47 Part 15, UL 60950-1 Second Edition, IP52, CAN/CSA C22.2 No. 60950-1-07, EN 50581, IEC 62471, IEC 60950-1:2005 + A1:2009 + A2:2013, EN 55032 Class B, ICES-003 issue 6 Class B, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013 |
| Power | |
| Battery | Lithium Ion |
| Dimensions & Weight | |
| Width | 6.6 cm |
| Depth | 9 cm |
| Height | 17.5 cm |
| Weight | 214 g |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Drop Specification | 1.5 m to concrete |
Features - Zebra - DS2278-HC0000BZZRW
More Details
Product Code
V36C671
