Zebra DS3608-DP - Barcode scanner - handheld - decoded | DS3608-DP20003VZWW
Please sign in so that we can notify you about a reply
Product Features
- Superior performance
When it comes to capturing barcodes in the manufacturing plant, the DS3608-DP and DS3678-DP deliver the ultimate in scanning performance - period. Capture direct part marks regardless of size, surface, contrast, density or type - including challenging dot peen, chemical or laser etch, ink, inkjet mold, cast or thermal spray marks. And workers can capture any 1D or 2D barcode displayed on a screen or printed on a label in practically any condition for superior barcode capture flexibility in a single scanner. - Ultra-rugged design
The warehouse and manufacturing plant floor is as tough as its gets. The ultra-rugged scanner. The corded and cordless models are the only scanners in this class that are dust-tight, sprayproof and waterproofed to IP67, with an IP65-sealed cradle for a complete rugged cordless solution. - Unrivaled manageability
With our complimentary industry-best tools, managing these scanners couldn't be easier. You can remotely configure and upgrade your scanners, format data properly for instant transmission into your business applications, monitor battery statistics for your cordless models and more.
Special Fetures
- Superior performance
- Ultra-rugged design
- Unrivaled manageability
Product Specification
| Type | Barcode scanner - handheld |
| Colour | Industrial green |
| Barcode | |
| Minimum Bar Width | 3 mil |
| Sensor Resolution | 1280 x 960 |
| Max Working Distance | 35 cm |
| Skew (Degrees) | 60 |
| Pitch (Degrees) | 60 |
| Print Contrast Signal (PCS) | 15% |
| Decode Capability | Code 93, Industrial 2 of 5, Code 39, NW-7, GS1 DataBar, QR code, MaxiCode, Aztec code, MicroPDF417, Code 3 of 5, Italy Pharmacode, Codabar, Code 128, Code 11, PDF417, MSI-Plessey, Data Matrix, TLC39, Micro QR code, China Han Xin Code, Direct Part Mark (DPM), UPC/EAN supplementals |
| TTL Decoding | Decoded |
| Connectivity Technology | Wired |
| OK Notification | Beeper, LED indicator, vibration |
| Features | Rugged |
| Miscellaneous | |
| Compliant Standards | UL, VDE, EN 61000-6-2, RoHS, UL 60950-1 Second Edition, IP67, CAN/CSA C22.2 No. 60950-1-07, EN 61000-3-2:2006+A1:2009+A2:2009, IEC 60601-1-2:2007, EN 50581:2012, ICES-003 issue 5 Class B, IEC 62471:2006, EN 62471:2008, EN 60601-1-2:2007, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+AC:2011, EN 61000-3-3:2013, EN 55024:2010, EN 55022:2010/AC:2011, IEC 60950-1:2005 + A1:2009 + A2:2013, CU, FCC CFR47 Part 15 B Class B |
| Dimensions & Weight | |
| Width | 7.6 cm |
| Depth | 13.2 cm |
| Height | 18.5 cm |
| Weight | 309 g |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | |
| Min Operating Temperature | -30 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Drop Specification | 2.4 m to concrete |
Features - Zebra - DS3608-DP20003VZWW
More Details
Product Code
V357708
EAN Code
5656565656562
Manufacturer
Zebra
