Zebra DS8108-HC / Healthcare / barcode scanner / handheld / 2D imager / decoded / interface cable required | DS8108-HC4000BVZWW
Please sign in so that we can notify you about a reply
Zebra DS8108-HC / Healthcare / barcode scanner / handheld / 2D imager / decoded / interface cable required | DS8108-HC4000BVZWW
|
Description Health care providers need to equip their health care professionals with the necessary tools to provide the very best in patient care, every second of every day. With Zebra's DS8100-HC Series handheld imagers, now they can. The DS8100-HC Series is purpose-built for health care environments. It provides unparalleled performance on virtually every barcode in any condition, flexible user-selectable feedback modes designed for around-the-clock use and much more, all in a first-of-its-kind housing delivering maximum protection against the spread of bacteria. |
Product Specification
| Type | Barcode scanner - handheld |
| Colour | Healthcare white |
| Interface Type | Interface cable required |
| Minimum Bar Width | 3 mil |
| Scan Element Type | 2D imager |
| Sensor Resolution | 1280 x 960 |
| Scan Mode | Single-pass |
| Skew (Degrees) | 60 |
| Pitch (Degrees) | 60 |
| Print Contrast Signal (PCS) | 16% |
| Decode Capability | EAN/JAN, Code 93, Code 39, NW-7, GS1 DataBar, QR code, MaxiCode, Aztec code, MicroPDF417, Italy Pharmacode, Codabar, Code 128, Code 11, UPC, PDF417, MSI-Plessey, Data Matrix, Korea Post, Micro QR code, China Han Xin Code |
| TTL Decoding | Decoded |
| Connectivity Technology | Wired |
| OK Notification | Beeper, LED indicator |
| Features | PRZM Intelligent Imaging technology |
| Clock Speed | 800 MHz |
| Interfaces | 1 x USB ¦ 1 x RS-232 ¦ 1 x keyboard wedge ¦ 1 x IBM 468x/469x |
| Compliant Standards | EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class B, EN 61000-4-2, RoHS, FIPS 140-2, UL 60950-1, CAN/CSA C22.2 No. 60950-1-07, IP42, EN 50581, IEC 62471, FCC CFR47 Part 15 B Class B, EN 55032 Class B, ICES-003 issue 6 Class B, EN60950-1 (2nd Edition) + A11 + A1 + A12 + A2:2013, EN60950-1 (2nd Edition) + A1 + A2, EN 60601-1-2:2015 |
| Width | 6.6 cm |
| Depth | 10.7 cm |
| Height | 16.8 cm |
| Weight | 156 g |
| Service & Support | Limited warranty - 5 years |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Drop Specification | 1.8 m to concrete |
Features - Zebra Technologies - DS8108-HC4000BVZWW
More Details
Product Code
V367828
EAN Code
-
Manufacturer
Zebra Technologies
