Zebra ZD611T / Label printer / thermal transfer / Roll (1.5 / 6 cm) / 300 dpi / up to 152 mm/sec / USB 2.0, LAN, serial, USB host, Wi-Fi(ac), Bluetooth 4.2 | ZD6A123-T0EB02EZ
Product Features
- Technology for today, innovation for tomorrow
Technology is constantly advancing and so will ZD611 printers. They're engineered to power future printing at the highest level with an innovative architecture that can perform more operations simultaneously and evolve with emerging technology. - Premium printing performance
Rely on the ZD611 to help you power through - day after day. From outstanding print quality to portability for application flexibility to emerging technology to field-installable options, the ZD611 stands apart. - Operate with ease, securely
Backed by Zebra's innovative Print DNA software suite, ZD611 printers are incredibly simple to operate. Deploy them anywhere with setup tools, wizards and emulation capabilities. The intuitive user interface is easy to use with minimal training and allows you to see status at a glance with the five LED icons. Take advantage of robust remote management capabilities that alleviate IT burdens. And, built-in security hardens your infrastructure from cyberattacks. - Load media easily
Color-coded touch points and a media-handling design guide you through speedy media changes to keep your printers operational and your workers on task. Replace ribbon intuitively and quickly with less mess, hassle and training time - and fewer calls into IT. - Engineered for outstanding print quality
Like Zebra's industrial printers, the ZD611 thermal transfer printer includes a media dancer to ensure maximum quality on every label and tag, regardless of print speed. - See printer status in color and change settings with a touch
Navigate easy-to-use menus and step-by-step wizards at a touch on the 4.3-inch, full-color LCD touch display. See status at a glance in color and troubleshoot with animations on the spot. The printers also feature media-loading and calibration guidance, and support stand-alone printing applications. Zebra touch displays are expertly designed and tested for toughness and reliability consistent with Zebra's printer portfolio, including robust tolerance to temperature, humidity, dust and other environmental challenges. - Backwards compatible with virtually any existing thermal printer
Integrate ZD611 printers into your existing fleet seamlessly. Continue to use the same label formats and applications you're using today. They support EPL and ZPL printer languages and can emulate other languages associated with other brands using Zebra's Print DNA Printer Emulations. - Comprehensive communication to connect your way
ZD611 printers can connect to your existing wired and wireless networks, or directly to any PC. Every ZD611 comes standard with Ethernet, USB 2.0 and USB Host. Print from any Windows, Android or iOS device, and integrate your ZD611 with Zebra's printer setup mobile app using Bluetooth Low Energy (BLE). And with the included Print Touch tag (NFC), you can simply tap a compatible mobile device on a ZD611 to pair and print - as well as instantly access Zebra's extensive knowledge base of how-to videos. - Add mobility for on-the-spot printing
Easily transport your ZD611 printer on a cart using the battery option. Print where you work to reduce steps and increase accuracy. Power through a full shift with the high-capacity battery. - Moveable sensor means more flexibility
The ZD611's movable media sensor allows for almost any media use, which means greater flexibility across a variety of use cases.
Special Features
- Technology for today, innovation for tomorrow
- Premium printing performance
- Operate with ease, securely
- Load media easily
- Engineered for outstanding print quality
- See printer status in color and change settings with a touch
- Backwards compatible with virtually any existing thermal printer
- Comprehensive communication to connect your way
- Add mobility for on-the-spot printing
- Moveable sensor means more flexibility
Product Specification
Printer Type | Label printer - thermal transfer - monochrome |
Printer | Printer |
Print Speed | Up to 152 mm/sec - max speed - 300 dpi |
Built-in Devices | 4.3 inch LCD touch screen |
Connectivity Technology | Wireless |
Interface | USB 2.0, LAN, serial, USB host, Wi-Fi(ac), Bluetooth 4.2 |
Max Resolution (B&W) | 300 dpi |
Language Simulation | ZPL II, EPL2, ZBI, Extensible Mark-up Language (XML), PDF Direct |
Features | Realtime clock, label dispenser, Print Touch tag, transmissive/gap sensor, reflective/black mark sensor |
Display Resolution | 480 x 272 |
Keyboard | 3 keys |
Fonts Included | 16 x bitmapped ZPL II 2 x scalable ZPL 5 x expandable EPL2 |
Barcodes | Code 93, Industrial 2 of 5, Code 39, Code 49, CODABLOCK, ISBT 128, QR code, MaxiCode, LOGMARS, UPC-A, UPC-E, Codabar, Code 128, Code 11, UPC, Interleaved 2 of 5, Postnet, PDF417, Data Matrix, PLANET, Plessey, Standard 2 of 5, EAN-8, EAN-13, MSI, Aztec, Micropdf |
RAM | RAM |
RAM Installed (Max) | 256 MB |
Technology / Form Factor | DDR3 SDRAM |
Flash Memory | Flash Memory |
Flash Memory | 512 MB |
Media Handling | Media Handling |
Media Type | Receipt paper, tag stock, continuous labels, die cut labels, wristband labels, fanfold labels |
Max Media Size | Roll (1.5 - 6 cm) |
Min Media Size (Custom) | 15 mm x 6.35 mm |
Max Media Size (Custom) | 57 mm x 991 mm |
Media Sizes | Roll (1.5 - 6 cm) |
Max Printing Width | 54 mm |
Media Thickness Range | 0.06 mm - 0.1905 mm |
Roll Maximum Outer Diameter | 127 mm |
Roll Core Diameter | 25.4 mm, 76.2 mm, 38.1 mm, 12.7 mm, 50.8 mm |
Media Feeders | 1 x manual - 1 roll - Roll (6 cm) |
Networking | Networking |
Networking | Print server |
Expansion / Connectivity | Expansion / Connectivity |
Connections | 1 x USB 2.0 - 4 pin USB Type B 1 x USB host - 4 pin USB Type A 1 x LAN - RJ-45 1 x RS-232 - 9 pin D-Sub (DB-9) |
Miscellaneous | Miscellaneous |
Included Accessories | Empty ribbon take-up core |
Cables Included | 1 x USB cable |
Features | Printer setup mobile app via BLE connection |
Compliant Standards | FCC Class B certified, VCCI, C-Tick, BSMI, EN 61000-3-2, ICES-003, NOM, SABS, EN55024, EN55022 Class B, FCC Part 15.247, CCC, IEC 60950-1, KCC, FCC Part 15.209, S Mark, cTUVus, EN 62311, EN 300 328, BIS, INMETRO, CU, RSS-247, IEC 62368-1, EN 301 893, REACH 2006/1907, RoHS 2011/65/EU Amendment 2015/863, EN61000-3-3, EN55035 |
Power | Power |
Power Device | Power adapter - external |
Voltage Required | AC 100-240 V |
Frequency Required | 50/60 Hz |
Power Factor Correction | Yes |
Software / System Requirements | Software / System Requirements |
Software Included | Link-OS |
Environmental Standards | Environmental Standards |
ENERGY STAR | Yes |
Manufacturer Warranty | Manufacturer Warranty |
Service & Support | Limited warranty - 2 years |
Environmental Parameters | Environmental Parameters |
Min Operating Temperature | 4.4 °C |
Max Operating Temperature | 41 °C |
Humidity Range Operating | 10 - 90% (non-condensing) |
Dimensions & Weight | Dimensions & Weight |
Width | 13.87 cm |
Depth | 24.29 cm |
Height | 16.92 cm |
Weight | 1.629 kg |
