Zebra ZT610 / Label printer / direct thermal / thermal transfer / Roll (10.8cm) / 300 dpi / up to 305 mm/sec / USB, serial, Gigabit LAN, USB host, NFC, Bluetooth 4.0 / peeler with liner rewind | ZT61043-T2E0100Z
Please sign in so that we can notify you about a reply
Product Features
- Exceptional performance from micro labels to high-volume shipping
Boost your productivity with printers that just won't quit. The ZT600 series features durable steel structural components that can withstand years of abuse in extreme temperatures, dust, debris and other challenging industrial conditions. Meticulously engineered printing mechanisms provide 24/7 reliability to meet your high-volume production needs. Plus, the ZT610 offers best-in-class print registration with 600 dpi micro consistent printing. - Hassle-free setup, daily use, maintenance and troubleshooting
From color-illuminated media and ribbon paths that help you identify problems quickly to easy-adjust printhead pressure toggles that feature a scale and color-coded pressure indicators to simplify printer setup and operation, every detail of the ZT600 series was designed to be user-friendly. Side loading capabilities eliminate the hassles of threading. Onboard sensors, diagnostics and help resources reduce the need for technical support. And guided instructions and feedback prevent common errors and reduce manual adjustments for highly consistent printing. - Operational visibility, remote management and future-ready adaptability
The ZT610 is as smart as they are powerful. Zebra's cloud-accessible Link-OS software platform and managed services offerings give you total visibility and control over your printing systems, whether you're on-site or across the globe. Plus, with two available communication slots, field-installable RFID encoder and media-handling options, and two USB host ports for Plug-and-Play integration, it's easy to stay ahead of your evolving business and technology needs, whatever they may be.
Special Features
- Exceptional performance from micro labels to high-volume shipping
- Hassle-free setup, daily use, maintenance and troubleshooting
- Operational visibility, remote management and future-ready adaptability
Product Specification
| Printer Type | Label printer - direct thermal / thermal transfer - monochrome |
| Localisation | United Kingdom, Europe |
| Printer | Printer |
| Print Speed | Up to 305 mm/sec - max speed |
| Built-in Devices | Status LCD, peeler with liner rewind |
| Connectivity Technology | Wireless |
| Interface | USB, serial, Gigabit LAN, USB host, NFC, Bluetooth 4.0 |
| Max Resolution (B&W) | 300 dpi |
| Language Simulation | ZPL, ZPL II, Extensible Mark-up Language (XML) |
| Fonts | CG Triumvirate Bold Condensed, OCR-A, OCR-B |
| Styles & Effects | Mirror, rotated text |
| Features | Realtime clock, transmissive media sensor, reflective media sensor, peeler with liner rewind |
| Display Resolution | 240 x 320 |
| Fonts Included | 16 x bitmapped ¦ 2 x scalable |
| Barcodes | Code 93, Industrial 2 of 5, Code 39, Code 49, CODABLOCK, ISBT 128, QR code, MaxiCode, Aztec code, LOGMARS, UPC-A, UPC-E, MicroPDF417, Codabar, Code 11, Interleaved 2 of 5, Postnet, PDF417, Data Matrix, PLANET, TLC39, Plessey, Code 128B, Code 128C, Code 128A, Standard 2 of 5, EAN-8, EAN-13, MSI, RSS-14 |
| Printer Features | Multi-level Element Energy Equalizer (E3) |
| Processor | Processor |
| Processor | Cortex-A9 800 MHz |
| RAM | RAM |
| RAM Installed (Max) | 1 GB |
| Technology / Form Factor | SDRAM |
| Flash Memory | Flash Memory |
| Flash Memory | 2 GB |
| Media Handling | Media Handling |
| Media Type | Continuous labels, die cut labels |
| Max Media Size | Roll (10.8cm) |
| Min Media Size (Custom) | 20 mm x 6 mm |
| Max Media Size (Custom) | 108 mm |
| Media Sizes | Roll (2 - 10.8 cm) |
| Max Printing Width | 104 mm |
| Max Printing Length | 2540 mm |
| Media Thickness Range | 0.076 mm - 0.305 mm |
| Roll Maximum Outer Diameter | 203 mm |
| Roll Core Diameter | 76 mm |
| Media Feeders | 1 x manual - 1 roll - Roll (10.8cm) |
| Networking | Networking |
| Networking | Print server |
| Expansion / Connectivity | Expansion / Connectivity |
| Connections | 1 x RS-232 - 9 pin D-Sub (DB-9) ¦ 1 x USB - 4 pin USB Type B ¦ 1 x Gigabit LAN - RJ-45 ¦ 2 x USB host - 4 pin USB Type A |
| Miscellaneous | Miscellaneous |
| Included Accessories | Peeler, spindle, rewind, bi-fold door |
| Features | Clear door |
| Compliant Standards | FCC Class B certified, VCCI, C-Tick, BSMI, EN 61000-3-2, ICES-003, NOM, EN 61000-3-3, EN55024, EN55022 Class B, CCC, IEC 60950-1, KCC, GOST-R, S Mark, cTUVus, UkrSEPRO |
| Power | Power |
| Power Device | Power supply - internal |
| Voltage Required | AC 120/230 V |
| Frequency Required | 50/60 Hz |
| Power Factor Correction | Yes |
| Environmental Standards | Environmental Standards |
| ENERGY STAR | Yes |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 5 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 20 - 85% (non-condensing) |
| Dimensions & Weight | Dimensions & Weight |
| Width | 26.82 cm |
| Depth | 50.5 cm |
| Height | 39.568 cm |
| Weight | 22.7 kg |
