ZOTAC ZBOX C Series CI337 nano - Barebone - mini PC - 1 x N-series N100 / 0.8 GHz - RAM 0 GB - UHD Graphics - Gigabit Ethernet, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6) - 802.11a/b/g/n/ac/ax, Bluetooth 5.2 | ZBOX-CI337NANO-BE
Please sign in so that we can notify you about a reply
Product Specification
| Type | PC barebone |
| Product Form Factor | Mini PC |
| Processor / Chipset | |
| CPU | Intel N-series N100 |
| Clock Speed | 0.8 GHz |
| Max Turbo Speed | 3.4 GHz |
| Number of Cores | Quad-Core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Processor Main Features | Intel Smart Cache |
| Cache Memory | |
| Installed Size | 6 MB |
| Cache Per Processor | 6 MB |
| RAM | |
| Installed Size | 0 GB / 16 GB (max) |
| Technology | DDR5 SDRAM |
| Effective Memory Speed | 4800 MHz |
| Rated Memory Speed | 4800 MHz |
| Form Factor | SO-DIMM 262-pin |
| Slots | 1 (Total) / 1 (empty) |
| Hard Drive | |
| Type | No HDD |
| Storage Controller | |
| Type | SATA |
| Controller Interface Type | SATA 6Gb/s |
| Channel Qty | 1 |
| Optical Storage | |
| Type | No optical drive |
| Card Reader | |
| Type | 3 in 1 card reader |
| Supported Flash Memory Cards | SD Memory Card, SDHC Memory Card, SDXC UHS-II Memory Card |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel UHD Graphics |
| Max Monitors Supported | 3 |
| Audio Output | |
| Sound Output Mode | Stereo |
| Networking | |
| Ethernet Ports | 2 x Gigabit Ethernet |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6) |
| Expansion / Connectivity | |
| Bays | 1 (total) / 1 (free) x internal 2.5" |
| Slots | 1 (total) / 1 (free) x M.2 Card - 2242 (SATA/PCIe 3.0 x1 (NVMe)) |
| Interfaces | 1 x DisplayPort (1 rear) ¦ 2 x HDMI (2 rear) ¦ 2 x LAN (Gigabit Ethernet) - RJ-45 (2 rear) ¦ 3 x USB 3.2 (1 front, 2 rear) ¦ 1 x headphones - mini-jack (1 front) ¦ 1 x microphone - mini-jack (1 front) ¦ 1 x USB-C 3.2 (1 front) |
| Miscellaneous | |
| Included Accessories | VESA mounting kit, Wi-Fi aerial, Screw kit for VESA mount |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| Compliant Standards | DisplayPort 1.4 |
| Power | |
| Device Type | Power adapter |
| Power Provided | 40 Watt |
| Operating System / Software | |
| OS Provided | No operating system |
| OS Certified | Windows 11 |
| Dimensions & Weight | |
| Width | 12.68 cm |
| Depth | 12.78 cm |
| Height | 5.68 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 23.5 cm |
| Shipping Depth | 23.5 cm |
| Shipping Height | 8.8 cm |
Features - ZOTAC - ZBOX-CI337NANO-BE
More Details
Product Code
03:222107
EAN Code
4895173626685
Manufacturer
ZOTAC
