Zyxel GS1900-8 - Switch - smart - 8 x 10/100/1000 - desktop, wall-mountable | GS1900-8-EU0102F

Product Features
- Versatility and flexibility for different needs
The complete ZyXEL GS1900 series comes with compact size and GbE connectivity. It supports multiple deployment methods to fulfill the needs for small offices and meeting room environments such as wall-, under table- or desktop-mounting options. It's now quick and effortless to enjoy the high-speed business network applications without a hitch. - Simple, intuitive wizard set up
For small businesses that want to manage their infrastructure in advance, the ZyXEL GS1900 series comes with a friendly built-in web-based browser for simple configuration and management. Moreover, the friendly step-by-step intuitive wizard helps avoiding multiple complicated configuration pages for quick set up with few clicks in the matter of minutes. To guide the users from start-up, VLAN, Guest VLAN to QoS setting, the complex steps have been combined into four quick individual steps; which does not just save deployment time and efforts, but is also helpful especially for the non-IT staff. - Avoiding network errors with easy management
The ZyXEL GS1900 series is equipped with advanced management features to make the network stable and secure: loop protection that prevents network flooding, dual images to provide a backup FW if one crashes and storm control to ensure network efficiency, friendly on/off DoS with simple click to enable/disable instead of several setup pages, while SSL ensures the management frames are well encrypted when the device is accessed. The GS1900 series provides network error prevention features and integrated network security for reduced risk and improved data streaming. - Energy saving for IEEE 802.3az
As operating overheads such as electric bills increase constantly due to the arising green awareness, businesses have to avoid unnecessary energy waste. The built-in IEEE 802.3az Energy Efficient Ethernet (EEE) and more ZyXEL green features of ZyXEL GS1900 series can reduce energy consumption of Ethernet devices through multiple intelligent ways.
Special Fetures
- 10/100/1000 Mbps GbE ports
- Easy browser-based switch management
- Quick and easy set up wizard
- Advanced network error prevention features
- Fanless design
- Green Ethernet IEEE 802.3az support and intelligent ZyXEL green features
Product Specification
Device Type | Switch - 8 ports - smart |
Enclosure Type | Desktop, wall-mountable |
Subtype | Gigabit Ethernet |
Ports | 8 x 10/100/1000 |
Performance | Switching capacity: 16 Gbps ¦ Forwarding performance: 11.9 Mpps ¦ Packet buffer size: 525 KB |
MAC Address Table Size | 8K entries |
Jumbo Frame Support | 9KB |
Routing Protocol | IGMPv2, IGMP, IGMPv3, MSTP, RSTP, STP |
Remote Management Protocol | SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3 |
Encryption Algorithm | SSL |
Authentication Method | RADIUS, TACACS+ |
Features | Flow control, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, DoS attack prevention, WRR queuing, store and forward, IPv6 support, QoS, fanless, LACP support, LLDP support, Port Security, MIB, SPQ, CoS, tagged VLAN, ZON, LAG |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3az |
Status Indicators | Power, system, link/activity |
Expansion / Connectivity | |
Interfaces | 8 x 1000Base-T RJ-45 |
Power | |
Power Device | External power adapter |
Voltage Required | AC 100-240 V (50/60 Hz) |
Power Consumption Operational | 5 Watt |
Miscellaneous | |
Included Accessories | Wall mounting kit |
MTBF | 1,146,942 hours |
Compliant Standards | RoHS, BSMI CNS 13438, BSMI CNS 14336-1, EN 62368-1, RCM Class A, EMI FCC Class A |
Dimensions & Weight | |
Width | 25 cm |
Depth | 10.4 cm |
Height | 2.7 cm |
Weight | 650 g |
Dimensions & Weight (Shipping) | |
Shipping Width | 30.2 cm |
Shipping Depth | 22.7 cm |
Shipping Height | 6.4 cm |
Shipping Weight | 1.04 kg |
Manufacturer Warranty | |
Service & Support | Limited warranty - lifetime |
Environmental Parameters | |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 40 °C |
Humidity Range Operating | 10 - 95% (non-condensing) |
Min Storage Temperature | -40 °C |
Max Storage Temperature | 70 °C |
Humidity Range Storage | 10 - 95% (non-condensing) |
